Toyota Forklift 6FD23
Toyota Forklift 6FD23

The Toyota Forklift 6FD23 is a robust industrial forklift designed for heavy-duty applications. Known for its reliability and efficiency, this model excels in material handling tasks, making it a preferred choice for warehouses and manufacturing facilities. Regular maintenance ensures optimal performance and longevity.

Turn manuals into instant answers
with your AI-powered assistant
Turn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Toyota Forklift 6FD23

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents

Documents & Manuals

Find all the essential guides in one place.

  • CheckTensioning Guide

  • CheckBelt-diagram

  • CheckC-120 pulleys

  • + 13 more

Work Orders

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

  • CheckDaily Electrical System Inspection

  • CheckReplace Roller and Pulley

  • CheckInstall Engine B-120

  • + 29 more

Procedures

Procedures

Integrate maintenance plans directly into your work orders.

  • CheckMotion Industries

  • CheckApplied Industrial Technologies

  • CheckElectrical Brothers

  • + 5 more

Parts

Parts

Access the parts list for your equipment in MaintainX.

  • CheckDrive Motor

  • CheckB2 Rollers

  • CheckTensioning System

  • + 40 more

Toyota Forklift 6FD23

Toyota Forklift 6FD23

Create an account to install this asset package.

Maintenance Plans for Toyota Forklift Model 6FD23

Integrate maintenance plans directly into your work orders in MaintainX.

2 Year Replacement

Check mark

Power steering hoses replaced

Check mark

Power steering rubbers parts replaced

Check mark

Hydraulic hoses replaced

Check mark

Brake fluid reservoir tank hose replaced

Check mark

Fuel hoses replaced

Check mark

Torque converter rubber hoses replaced

Check mark

Note: Chains are replaced every 3 years

Check mark

Sign off on the 2 year replacement

Run this procedureArrow right

170 Hour / 1 Month Steering System Maintenance

Check mark

- Inspect for play and looseness in the steering wheel

Check mark

- Inspect the function of the steering wheel

Check mark

- Inspect gear box for oil leak

Check mark

- Retighten looseness of mounting of the gear box

Check mark

- Inspect rod, links and arm for looseness and damage

Check mark

- Inspect for oil leaks in the power steering

Check mark

- Inspect power steering for looseness in mounting and linkage; - Inspect knuckle for king pin looseness;

Run this procedureArrow right

1000 Hour / 6 Month Maintenance

Check mark

Measure injection timing in fuel system

Check mark

Inspect draining of sedimenter in fuel system

Check mark

Inspect oil clutch mechanism function and leak

Check mark

Measure stall and hydraulic pressure in torque converter and transmission

Check mark

Clean clogging of relief valve filter

Check mark

Clean hydraulic oil tank and oil strainer

Check mark

Sign off on the 1000 Hour / 6 Month Maintenance

Run this procedureArrow right

170 Hour / 1 Month Electrical System Inspection

Check mark

Inspect for cracks on the distributor cap

Check mark

Inspect for spark plug burning and measure the gap

Check mark

Inspect for burning on the distributor side terminal

Check mark

Inspect for wear and damage on the distributor cap center piece

Check mark

Inspect pinion gear meshing status in starting motor

Check mark

Inspect charger function

Check mark

Inspect battery fluid level

Check mark

Inspect wiring harness for damage

Check mark

Inspect the fuses

Run this procedureArrow right

170 Hour / 1 Month Power Transmission System Maintenance

Check mark

Measure clutch pedal play

Check mark

Inspect clutch for abnormal sound and functioning

Check mark

Inspect clutch master cylinder function and leak

Check mark

Inspect clutch fluid level

Check mark

Inspect transmission for leak

Check mark

Inspect transmission fluid level

Check mark

Inspect transmission gear function and abnormal noise

Check mark

Inspect for leaks in the differential

Check mark

Inspect differential oil level

Run this procedureArrow right

Parts for Toyota Forklift 6FD23

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Axle Hub and Drive Pinion Bearing Tool Set

09608-35014

Front Hub and Drive Pinion Bearing Replacer Set

09608-20012

Oil Filter Wrench

09228-07500

Main Shaft Preload

09470-10171-71

Brake Shoe Return Spring Remover

09717-20010

Axle Hub and Drive Pinion Bearing Tool Set

09608-35014

Front Hub and Drive Pinion Bearing Replacer Set

09608-20012

Oil Filter Wrench

09228-07500

Main Shaft Preload

09470-10171-71

Brake Shoe Return Spring Remover

09717-20010

Axle Hub and Drive Pinion Bearing Tool Set

09608-35014

Front Hub and Drive Pinion Bearing Replacer Set

09608-20012

Oil Filter Wrench

09228-07500

Main Shaft Preload

09470-10171-71

Brake Shoe Return Spring Remover

09717-20010
