Toyota Forklift 60 - 6FD28

Inspect linkage wear and mounting condition of the rods, links and arm

Inspect damage of power steering hose

Inspect cracks and deformation in knuckle

Measure wheel alignment in steering shaft

Measure steering shaft left turning angle

Measure steering shaft right turning angle

Sign off on the steering system inspection

Measure play and reserve in the brake pedal

Inspect the braking effect of the brake pedal

Inspect the operating force of the parking brake

Inspect the braking effect of the parking brake

Inspect for looseness or damage in the parking brake rod and cable

Inspect for leaks, damage, and mounting condition of the brake pipe

Inspect for leaks and fluid level in the reservoir tank

Measure clearance between drum and lining

Sign off on the braking system maintenance

- Replace cups and seals for brake master and wheel cylinders;

Measure tire inflation pressure of the wheels

Inspect for tire cuts, damage, and uneven wearing

Tighten for loose rim and hub nuts

Inspect for metal chips, pebbles, or foreign matter trapped in tire grooves

Inspect rim, side bearing, and disc wheel for damage

Inspect for abnormal sound and looseness in the front wheel bearing

Inspect for abnormal sound and looseness in the rear wheel bearing

Inspect clutch for abnormal sound and functioning

Inspect clutch master cylinder function and leak

Inspect transmission fluid level

Inspect transmission gear function and abnormal noise

Inspect for leaks in the differential
