Toyota Forklift 5FBC30

Need answers fast?
Explore the manual using AI.

Toyota Forklift 5FBC30
Toyota Forklift 5FBC30

Turn manuals into instant answers
with your AI-powered assistant
Turn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Toyota Forklift 5FBC30

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents

Documents & Manuals

Find all the essential guides in one place.

  • CheckTensioning Guide

  • CheckBelt-diagram

  • CheckC-120 pulleys

  • + 13 more

Work Orders

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

  • CheckDaily Electrical System Inspection

  • CheckReplace Roller and Pulley

  • CheckInstall Engine B-120

  • + 29 more

Procedures

Procedures

Integrate maintenance plans directly into your work orders.

  • CheckMotion Industries

  • CheckApplied Industrial Technologies

  • CheckElectrical Brothers

  • + 5 more

Parts

Parts

Access the parts list for your equipment in MaintainX.

  • CheckDrive Motor

  • CheckB2 Rollers

  • CheckTensioning System

  • + 40 more

Toyota Forklift 5FBC30

Toyota Forklift 5FBC30

Create an account to install this asset package.

Maintenance Plans for Toyota Forklift Model 5FBC30

Integrate maintenance plans directly into your work orders in MaintainX.

170 Hour / 1 Month Hydraulic System Maintenance

Check mark

Inspect loosening and damage of cylinder mounting

Check mark

Inspect deformation and damage of rod and rod end

Check mark

Inspect cylinder operation

Check mark

Inspect natural drop and natural forward tilt

Check mark

Inspect cylinder oil leak and damage

Check mark

Inspect wear and damage of pin and cylinder bearing

Check mark

Measure cylinder lifting speed

Check mark

Inspect cylinder uneven movement

Check mark

Inspect oil leak and abnormal sound in oil pump

Run this procedureArrow right

2000 Hour / 12 Month Steering System Maintenance

Check mark

Inspect damage of power steering hose

Check mark

Inspect cracks and deformation in knuckle

Check mark

Measure wheel alignment

Check mark

Measure left turning angle

Check mark

Measure right turning angle

Check mark

Sign off on the steering system maintenance

Run this procedureArrow right

170 Hour / 1 Month Maintenance

Check mark

Inspect head guard cracks at welded portion

Check mark

Inspect head guard deformation and damage

Check mark

Retighten loosening of mounting in back-rest

Check mark

Inspect back-rest for deformation, crack and damage

Check mark

Inspect function and mounting condition of lighting system

Check mark

Inspect function and mounting condition of horn

Check mark

Inspect function and mounting condition of direction indicator

Check mark

Inspect function and mounting condition of back up buzzer

Check mark

Inspect instruments functions

Run this procedureArrow right

2000 Hour / 12 Month Replacement

Check mark

Differential oil replaced

Check mark

Transmission oil replaced

Check mark

Wheel bearing grease replaced

Check mark

Master cylinder rubber parts replaced

Check mark

Wheel cylinder rubber parts replaced

Check mark

Sign off on the replacement procedure

Run this procedureArrow right

170 Hour / 1 Month Travelling Equipment System Maintenance

Check mark

Inspect wheels for tire cuts, damage and uneven wearing

Check mark

Retighten loose rim and hub nuts in wheels

Check mark

Measure tire groove depth in wheels

Check mark

Inspect metal chips, pebbles and other foreign matter trapped in tire grooves

Check mark

Inspect rim and disc wheel damage

Check mark

Inspect abnormal sound and looseness of front wheel bearing

Check mark

Inspect abnormal sound and looseness of rear wheel bearing

Check mark

Sign off on the travelling equipment system maintenance

Run this procedureArrow right

Parts for Toyota Forklift 5FBC30

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Universal Joint Flange Holding Tool

09330-30010

Rear Wheel Bearlng Nut Wrench

09509-55020

Front Hub & Drive Pinion Bearing Tool Set

09608-30012

Axle Hub & Drive Pinion Bearing Tool Set

09608-35014

Steering Wheel Puller

09609-20011

Universal Joint Flange Holding Tool

09330-30010

Rear Wheel Bearlng Nut Wrench

09509-55020

Front Hub & Drive Pinion Bearing Tool Set

09608-30012

Axle Hub & Drive Pinion Bearing Tool Set

09608-35014

Steering Wheel Puller

09609-20011

Universal Joint Flange Holding Tool

09330-30010

Rear Wheel Bearlng Nut Wrench

09509-55020

Front Hub & Drive Pinion Bearing Tool Set

09608-30012

Axle Hub & Drive Pinion Bearing Tool Set

09608-35014

Steering Wheel Puller

09609-20011
