Toyota Forklift 5FBC15

Need answers fast?
Explore the manual using AI.

Toyota Forklift 5FBC15
Toyota Forklift 5FBC15

Turn manuals into instant answers
with your AI-powered assistant
Turn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Toyota Forklift 5FBC15

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents

Documents & Manuals

Find all the essential guides in one place.

  • CheckTensioning Guide

  • CheckBelt-diagram

  • CheckC-120 pulleys

  • + 13 more

Work Orders

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

  • CheckDaily Electrical System Inspection

  • CheckReplace Roller and Pulley

  • CheckInstall Engine B-120

  • + 29 more

Procedures

Procedures

Integrate maintenance plans directly into your work orders.

  • CheckMotion Industries

  • CheckApplied Industrial Technologies

  • CheckElectrical Brothers

  • + 5 more

Parts

Parts

Access the parts list for your equipment in MaintainX.

  • CheckDrive Motor

  • CheckB2 Rollers

  • CheckTensioning System

  • + 40 more

Toyota Forklift 5FBC15

Toyota Forklift 5FBC15

Create an account to install this asset package.

Maintenance Plans for Toyota Forklift Model 5FBC15

Integrate maintenance plans directly into your work orders in MaintainX.

170 Hour / 1 Month Electrical System Maintenance

Check mark

Inspect motor abnormal sound during revolution

Check mark

Retighten looseness in the connecting parts of the motor

Check mark

Inspect battery charge

Check mark

Inspect battery fluid level

Check mark

Measure battery fluid specific gravity

Check mark

Inspect looseness in the connecting parts of the battery

Check mark

Inspect abnormality in the upper portion of the battery case

Check mark

Inspect timer operation of the charger

Check mark

Inspect terminal loosening in charger

Run this procedureArrow right

1000 Hour / 6 Month Maintenance

Check mark

Inspect brush wear and sliding contact status of the motor

Check mark

Inspect motor commutator fouling and damage

Check mark

Clean hydraulic oil tank and oil strainer

Check mark

Replace hydraulic oil

Check mark

Replace brake fluid

Check mark

Sign off on the 1000 Hour / 6 Month Maintenance

Run this procedureArrow right

170 Hour / 1 Month Material Handling System Inspection

Check mark

Inspect abnormality of fork and stopper pin

Check mark

Inspect misalignment between left and right fork fingers

Check mark

Inspect deformation and damage of each part and crack at welded part

Check mark

Inspect mast and lift bracket looseness

Check mark

Inspect wear, damage and rotating condition of rollers

Check mark

Inspect wear and damage of mast strip

Check mark

Inspect tension, deformation and damage of chain

Check mark

Inspect chain lubrication

Check mark

Inspect abnormality of chain anchor bolt

Run this procedureArrow right

2000 Hour / 12 Month Braking System Maintenance

Check mark

Inspect parking brake for ratchet wear and damage

Check mark

Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

Check mark

Inspect wear of shoe sliding portion and lining

Check mark

Inspect drum wear and damage

Check mark

Inspect shoe operating condition

Check mark

Inspect anchor pin rusting

Check mark

Measure return spring fatigue

Check mark

Inspect automatic adjuster function

Check mark

Inspect backing plate for deformation, cracks and damage

Run this procedureArrow right

170 Hour / 1 Month Travelling Equipment System Maintenance

Check mark

Inspect wheels for tire cuts, damage and uneven wearing

Check mark

Retighten loose rim and hub nuts in wheels

Check mark

Measure tire groove depth in wheels

Check mark

Inspect metal chips, pebbles and other foreign matter trapped in tire grooves

Check mark

Inspect rim and disc wheel damage

Check mark

Inspect abnormal sound and looseness of front wheel bearing

Check mark

Inspect abnormal sound and looseness of rear wheel bearing

Check mark

Sign off on the travelling equipment system maintenance

Run this procedureArrow right

Parts for Toyota Forklift 5FBC15

Access the parts list for your equipment in MaintainX.

Part Name
Part Number

Universal Joint Flange Holding Tool

09330-30010

Rear Wheel Bearlng Nut Wrench

09509-55020

Front Hub & Drive Pinion Bearing Tool Set

09608-30012

Axle Hub & Drive Pinion Bearing Tool Set

09608-35014

Steering Wheel Puller

09609-20011

Universal Joint Flange Holding Tool

09330-30010

Rear Wheel Bearlng Nut Wrench

09509-55020

Front Hub & Drive Pinion Bearing Tool Set

09608-30012

Axle Hub & Drive Pinion Bearing Tool Set

09608-35014

Steering Wheel Puller

09609-20011

Universal Joint Flange Holding Tool

09330-30010

Rear Wheel Bearlng Nut Wrench

09509-55020

Front Hub & Drive Pinion Bearing Tool Set

09608-30012

Axle Hub & Drive Pinion Bearing Tool Set

09608-35014

Steering Wheel Puller

09609-20011
