Toyota Forklift 5FB18

Measure brake pedal play and reserve

Inspect braking effect in brake pedal

Inspect pull margin, braking effect, rod and cable looseness and damage of the parking brake

Inspect leak, damage and mounting condition of the brake pipe

Measure clearance between drum and lining

Sign off on the braking system maintenance

Inspect head guard cracks at welded portion

Inspect head guard deformation and damage

Retighten loosening of mounting in back-rest

Inspect back-rest for deformation, crack and damage

Inspect function and mounting condition of lighting system

Inspect function and mounting condition of horn

Inspect function and mounting condition of direction indicator

Inspect function and mounting condition of back up buzzer

Measure tire inflation pressure

Inspect wheels for tire cuts, damage and uneven wearing

Retighten loose rim and hub nuts in wheels

Measure tire groove depth in wheels

Inspect metal chips, pebbles and other foreign matter trapped in tire grooves

Inspect rim and disc wheel damage

Inspect abnormal sound and looseness of front wheel bearing

Inspect abnormal sound and looseness of rear wheel bearing

Measure looseness of axle beam in vehicle longitudinal direction while forklift is new

Measure relief pressure in oil control valve

Inspect damage and cracks of frame, cross members, etc.

Retighten bolt looseness in body

Internal rubbers parts of power steering system replaced

Material handling hose replaced

Note: EPS actuator grease should be replaced every 4 years

Sign off on the 2 Year Replacement
