Toyota Forklift 52-6FGCU30
Need answers fast?
Explore the manual using AI.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Toyota Forklift 52-6FGCU30
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Toyota Forklift 52-6FGCU30
Create an account to install this asset package.
Maintenance Plans for Toyota Forklift Model 52-6FGCU30
Integrate maintenance plans directly into your work orders in MaintainX.
170 Hour / 1 Month Electrical System Inspection
Inspect for cracks on the distributor cap
Inspect for spark plug burning and measure the gap
Inspect for burning on the distributor side terminal
Inspect for wear and damage on the distributor cap center piece
Inspect pinion gear meshing status
Inspect charger function
Inspect battery fluid level
Inspect wiring harness for damage
Inspect the fuses
2000 Hour / 12 Month Replacement
Replace differential oil
Replace Wheel bearing grease
Replace air cleaner element
Replace Cups and seals for brake master and wheel cylinders
Sign off on the replacement procedure
2000 Hour / 12 Month Braking System Maintenance
Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder
Inspect Wear of shoe sliding portion and lining
Inspect Drum wear and damage
Inspect Shoe operating condition
Inspect Anchor pin rusting
Measure Return spring fatigue
Inspect Automatic adjuster function
Inspect Backing plate for deformation, cracks and damage
Retighten Backing plate loose mounting
170 Hour / 1 Month Replacement
Engine oil replaced
Engine oil filters replaced
Hydraulic oil filter replaced
500 Hour / 3 Month Replacement
Engine oil filter replaced
Engine coolant replaced
Sign off on the replacement procedure
1000 Hour / 6 Month Maintenance
Measure stall and hydraulic pressure in torque converter and transmission
Clean hydraulic oil tank and oil strainer
Measure ignition timing
Measure battery fluid specific gravity
Sign off on the 1000 Hour / 6 Month Maintenance
