Toyota Forklift 30-8FGJ35

Replace torque converter oil filter

Replace DPF Mafler back pressure sensor inline filter (OPT)

Measure wheels tire inflation pressure in drive system

Inspect wheels tire cuts, damage and uneven wearing in drive system

Retighten wheels loose rim and hub nuts in drive system

Measure wheels tire groove depth in drive system

Inspect wheels metal chips, pebbles and other foreign matter trapped in tire grooves in drive system

Inspect wheels rim, side bearing and disc wheel damage

Inspect wheels abnormal sound and looseness of front wheel bearing

Inspect wheels abnormal sound and looseness of rear wheel bearing

Inspect cracks at fork root and welded part while forklift is new

Inspect wear and damage of mast support bushing

Inspect wear and damage of roller pins

Oil pump seal for material handling replaced

DPF Mafler filter replaced (Optional)

Enter the current machine hours

SAS Swing lock cylinder replaced (if machine hours > 10000)

3-way catalytic muffler replaced (if machine hours > 3500 or 5 years passed)

Sign off on the 3 Year Replacement

Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

Inspect Wear of shoe sliding portion and lining

Inspect Shoe operating condition

Inspect Automatic adjuster function

Inspect Backing plate for deformation, cracks and damage

Retighten Backing plate loose mounting
