Toyota Forklift 30-5FB25

Measure motor brush spring fatigue

Measure voltage of each battery cell after charging

Inspect magnet switch function, contact fouling and roughening in charger

Inspect installation status of the arc shooter

Inspect magnet contactor's function and timing

Inspect looseness of the coil mounting parts

Inspect loose main circuit lead installation

Measure controller overcurrent limit valve

Sign off on the electrical system inspection

Inspect linkage wear and mounting condition in rods, links and arms

Inspect damage of power steering hose

Inspect power steering sensor function

Inspect cracks and deformation in knuckle

Measure left and right turning angle of steering shaft

Sign off on the steering system maintenance

Measure tire inflation pressure

Inspect wheels for tire cuts, damage and uneven wearing

Retighten loose rim and hub nuts in wheels

Measure tire groove depth in wheels

Inspect metal chips, pebbles and other foreign matter trapped in tire grooves

Inspect rim and disc wheel damage

Inspect abnormal sound and looseness of front wheel bearing

Inspect abnormal sound and looseness of rear wheel bearing

Measure looseness of axle beam in vehicle longitudinal direction while forklift is new

Inspect brush wear and sliding contact status of the motor

Inspect motor commutator fouling and damage

Replace hydraulic oil return filter

Sign off on the 1000 Hour / 6 Month Maintenance

Inspect steering wheel's function, play and looseness

Retighten looseness of mounting in gear box

Inspect power steering for oil leak

Inspect rods, links and arm for looseness and damage

Inspect king pin looseness of the knuckle

Sign off on the steering system maintenance
