Toyota Forklift 02- 6FG28

Inspect loosening and damage of cylinder mounting

Inspect deformation and damage of rod, rod screw and rod end

Measure natural drop and natural forward tilt

Inspect for oil leaks and damage in the cylinder

Inspect for wear and damage of the pin and cylinder bearing

Inspect cylinder for uneven movement

Inspect for oil leaks and abnormal sound from the oil pump

Retighten differential bolt loosening

Inspect Looseness at spline connections

Inspect Looseness of universal joint

Inspect Twisting and cracks of axle shaft

Sign off on the power transmission system maintenance

Retighten loose joint in propeller shaft

Retighten loose joint in axle shaft

- Inspect function, wear, damage, leak and mounting looseness in Master cylinder and wheel cylinder

- Inspect Wear of shoe sliding portion and lining

- Inspect Shoe operating condition

- Measure Return spring fatigue

- Inspect Automatic adjuster function

- Inspect Backing plate for deformation, cracks and damage

- Retighten Backing plate loose mounting;

Inspect for cracks on the distributor cap

Inspect for spark plug burning and measure the gap

Inspect for burning on the distributor side terminal

Inspect for wear and damage on the distributor cap center piece

Inspect pinion gear meshing status in starting motor

Inspect wiring harness for damage
