Sullair Industrial Air Compressor 4510P

Display on the WS Controller indicates the need for replacement

FLUID FILTER ELEMENT REPLACEMENT

Filter canister removed with a wrench

Filter element disposed properly

NOTE: Dispose of fluids in accordance with applicable federal, state, and local regulations.

Light film of fluid applied to the element seal

Warning: This procedure requires trained personnel with PPE!

Enter the machine's hour meter reading

Enter the date of the last hose replacement

If machine is air-cooled, order hose kit 02250171-102

If machine is water-cooled, order hose kit 02250171-103

Sign off on the hose replacement

Does the maintenance gauge show red with the compressor running full load?

Clean the air filter’s exterior housing.

Release the hold-down clips and remove the end cover.

Remove the air filter element by pulling it out of the housing.

Clean the housing interior with a damp cloth. DO NOT blow dirt out with compressed air.

Reassemble in the reverse order.

Sign off on the air filter replacement

Warning: Relieve all pressure from the receiver tank and all compressor lines before starting.

Pressure relieved from the receiver tank and all compressor lines?

Loosen and remove the eight (8) hex head capscrews (M12 x 40mm) from the cover plate.

Lift the cover plate from the receiver tank.

Inspect the receiver tank for rust, contamination, or damage.

Warning: This procedure requires trained personnel with PPE!

Is the strainer screen removed?

Is the strainer screen cleaned?

Is the strainer screen reinstalled?

If the screen is damaged, the strainer assembly must be replaced (P/N 241772).

Sign off on the strainer cleaning
