Skyjack Telescopic Boom SJ66 T+

Grease the machine at normal work

Note: Grease the machine at awkward work every 1 Week

Place a suitable container under the filter

Use a filter wrench to remove the filter from the head

Apply hydraulic oil to the o-ring on the new filter

Screw the new filter into place

Tighten the filter with the filter wrench

Sign off on the hydraulic filter replacement

Warning: Only trained personnel should perform this procedure

Oil sample drawn from the reservoir

Oil sample taken when oil is warmed through normal operation

Upload the oil sample test results

Enter the name of the lubrication specialist

Oil sample suitable for continued use

Sign off on the oil sample testing

Check Planetary reduction oil level

Replace differential oil every 800 Hours

Replace planetary reduction oil every 1000 Hours

Replace Self-locking differential gear oil every 700 Hours

Replace Gear box oil once at 50 Hours after every 1000 Hours

Sign off on the 200 Hourly Telescopic Boom Service

Turn the engine on and allow the hydraulic oil to warm up

Place a suitable container under the hydraulic tank

Remove the oil drain plug and allow all of the hydraulic oil to drain into the container

Reinstall the drain plug with a new seal ring and tighten the plug firmly

Refill the hydraulic tank with new oil

Clean up any oil that may have spilled during this procedure

Check the hydraulic oil level. The hydraulic oil level should be at or slightly above the fill line on the tank
