Skyjack Electric Scissors SJIII 3220

Storing the Maintenance Support

Turn main power disconnect switch to 'I' on position.

Raise platform until there is adequate clearance to swing up the maintenance support.

Swing bar fully up into storage bracket.

Deploying the Maintenance Support

Remove all material from platform.

Raise platform until there is adequate clearance to swing down maintenance support.

Swing maintenance support down from storage bracket into a vertical position.

Ensure no flames or sparks are near the battery area.

Wear proper eye and facial protection and appropriate protective clothing.

Turn main power disconnect switch to 'O' off position.

Check battery fluid level in each battery.

Are all battery plates covered by at least 13 mm of solution?

Add distilled or demineralized water if plates are not covered.
