Mitsubishi Split-Type Air Conditioner PUZ-A24NHA6
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type Air Conditioner Model PUZ-A24NHA6
Integrate maintenance plans directly into your work orders in MaintainX.
Fan Motor Replacement
Warning: Ensure the power is off before starting the procedure
Service panel removed
Top panel removed
Number of fan grille fixing screws removed
Propeller detached
Connector CNF1 disconnected
Number of fan motor fixing screws removed
Fan motor detached
Sign off on the fan motor replacement
TH7 Thermistor Replacement
Warning: Ensure the machine is powered off before starting the procedure.
Upload a photo of the service panel before removal
Service panel removed successfully
Upload a photo of the top panel before removal
Top panel removed successfully
Connector TH7 disconnected successfully
Upload a photo of the clamp for the lead wire before loosening
Clamp for the lead wire loosened successfully
Thermistor <Ambient> (TH7) pulled out successfully
Outdoor Unit Refrigirant Charging
Cautions for service
Refrigerant recovered from the unit completely
Refrigerant not released in the air
Cycle charged with specified amount of refrigerant after service
Filter drier installed for service
Additional refrigerant charge
Cylinder for R410A is a syphon type
Charging performed with the cylinder of syphon stood vertically
Service tools
Bypass Valve Replacement
Remove the service panel
Remove the top panel
Remove the electrical parts box
Remove 3 right side panel fixing screws (5 × 12) in the rear of the unit and remove the right side panel
Remove the bypass valve coil
Recover refrigerant
Remove the welded part of bypass valve
Note 1: Recover refrigerant without spreading it in the air
Note 2: The welded part can be removed easily by removing the right side panel
Electrical Parts Box Replacement
Upload a photo of the service panel before removal
Service panel removed successfully
Upload a photo of the top panel before removal
Top panel removed successfully
Indoor/outdoor connecting wire disconnected from terminal block
Remove all the following connectors
All connectors removed successfully
Terminal cover removed and compressor lead wire disconnected
Electrical parts box fixing screw removed
Parts for Mitsubishi Split-Type Air Conditioner PUZ-A24NHA6
Access the parts list for your equipment in MaintainX.
Inverter Starter Type, Hermetic Compressor - 1,3 KW
TNB220FLHM
Inverter Starter Type, Hermetic Compressor - 1,3 KW
TNB220FLHM
Inverter Starter Type, Hermetic Compressor - 1,3 KW
