Mitsubishi Split-Type Air Conditioner MUZ-GC71NA
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type Air Conditioner Model MUZ-GC71NA
Integrate maintenance plans directly into your work orders in MaintainX.
R.V. Coil Disassemble
Remove the top panel, cabinet and service panel
Remove the back panel
Disconnect the following connectors; <Noise filter P.C. board> CN912 (R.V. coil)
Remove the R.V. coil
Upload a photo of the disassembled R.V. coil
Sign off on the R.V. coil disassembly
Thermistors Disassemble
Remove the top panel, cabinet and service panel
Remove the back panel
Disconnect CN661 (Discharge temperature thermistor, defrost thermistor and outdoor heat exchanger temperature thermistor) from the Electronic control P.C. board
Disconnect CN663 (Ambient temperature thermistor) from the Electronic control P.C. board
Pull out the defrost thermistor from its holder
Upload a photo of the defrost thermistor after removal
Pull out the discharge temperature thermistor from its holder
Upload a photo of the discharge temperature thermistor after removal
Pull out the outdoor heat exchanger temperature thermistor from its holder
Compressor and 4-Way Valve Disassemble
Remove the top panel, cabinet and service panel
Remove the back panel
Remove the inverter assembly
Recover gas from the refrigerant circuit until the pressure gauge shows 0 kg/cm2 (0 MPa)
Detach the welded part of the suction and the discharge pipe connected with compressor
Remove the compressor nuts
Remove the compressor
Detach the welded part of 4-way valve and pipe
Upload a photo of the detached 4-way valve and pipe
Reactor Disassemble
Remove the top panel, cabinet, service panel and the back panel
Disconnect the reactor lead wire
Remove the screws of the reactor
Remove the reactor
Upload a photo of the disassembled reactor
Sign off on the reactor disassemble
Outdoor Fan Disassemble
Remove the top panel, cabinet and service panel
Remove the back panel
Disconnect the following connectors; <Electronic control P.C. board> CN931 and CN932 (Fan motor)
Remove the propeller
Remove the screws fixing the fan motor
Remove the fan motor
Parts for Mitsubishi Split-Type Air Conditioner MUZ-GC71NA
Access the parts list for your equipment in MaintainX.
Fan Motor
RC0J60-AA
Compressor
TNB220FMCHT
Fan Motor
RC0J60-AA
Compressor
TNB220FMCHT
Fan Motor
RC0J60-AA
Compressor
TNB220FMCHT
