Lincoln Electric FILTRATION UNIT DIGIFILTER 10CD

- Unscrew the flat nut that holds the cartridge fastened

- Place a plastic bag around the cartridge and remove it

- Put the clogged cartridge in the packaging of the new cartridge

- Put in the new cartridge, screw back the flat nut and close the doors

- Apply the starting up procedure.

- The filter must be purged regularly

- The air supply pipes must be inspected (for leaks) and changed if necessary.

- Damaged bearings must be replaced as soon as possible to prevent more significant damage to the motor and driven parts

- When a bearing needs to be replaced, the other bearing must also be replaced

- Seals must always be changed when bearings are changed

- The floating bearing must allow the expansion of the rotor shaft.

- The containers must be emptied regularly

- Switch off the power supply to the fan

- Open the dust container compartment

- Remote the container using equipment appropriate for the weight of the assembly

- If there is a bag, replace the bag inside and put the container in its place

- Put the unit back into service.
