Hussmann Merchandiser IM-05-10R

• Long life and satisfactory performance of any equipment are dependent upon the care given to it. To insure long life, proper sanitation and minimum maintenance costs, the refrigerator should be thoroughly cleaned frequently.

• SHUT OFF FAN DURING CLEANING PROCESS. It can be unplugged within the case, or shut off entire case at the source. The interior bottom may be cleaned with any domestic soap or detergent based cleaners.

• Sanitizing solutions will not harm the interior bottom, however, these solutions should always be used according to the Hussmann’s directions.; It is essential to establish and regulate cleaning procedures. This will minimize bacteria causing discoloration which leads to degraded product appearance and significantly shortening product shelf life.

• Soap and hot water are not enough to kill this bacteria. A sanitizing solution must be included with each cleaning process to eliminate this bacteria.

1. Scrub thoroughly, cleaning all surfaces, with soap and hot water.

2. Rinse with hot water, but do not flood.

3. Apply the sanitizing solution according to Hussmann’s directions.

Warning: Never use sharp objects around coils. Use a soft brush or vacuum brush to clean debris from coils.

Warning: Do not puncture coils! Do not bend fins.

Contact an authorized service technician if a coil is punctured, cracked, or otherwise damaged.

Do NOT use chlorine or ammonia-based cleaners to clean aluminum coils.

Is there ICE in or on the coil?

Contact an authorized service technician to determine the cause of icing, and to make adjustments as necessary.

To maintain product integrity, move all product to a cooler until the unit has returned to normal operating temperatures.

- Only use a soft cloth and mild glass cleaner for cleaning any glass or mirrored components. Be sure to rinse and/ or dry completely.

* Never use hot water on cold glass surfaces! It may shatter and cause serious injury! Allow glass surfaces to warm first.

When cleaning: • Do not use high pressure water hoses

• Do not introduce water faster then waste outlet can drain

• NEVER INTRODUCE WATER ON SELF CONTAINED UNIT WITH AN EVAPORATOR FAN

• NEVER USE A CLE NIN OR SANITIZING SOLUTION THAT HAS AN OIL BASE (these will dissolve the butyl sealants) or an AMMONIA BASE (this will corode the copper components of the case)

• TO PRESERVE THE ATTRACTIVE FINISH:

• DO USE WATER AND A MILD DETERGENT FOR THE EXTERIOR ONLY

DANGER! BEFORE SERVICING! ALWAYS DISCONNECT ELECTRICAL POWER AT THE MAIN DISCONNECT WHEN SERVICING OR REPLACING ANY ELECTRICAL COMPONENT. This includes (but not limited to) Fans, Heaters Thermostats, and Lights.

CAUTION! Fluorescent Lamps contain mercury vapor. Mercury exposure at high levels can harm the brain, heart, kidneys, lungs and immune system of people of all ages. Do not break or puncture fluorescent lamps. Dispose of, or store, all fluorescent lamps in accordance with Federal (40 CFR 273), State and local hazardous waste requirements.

Fluorescent lamps are furnished with a shatterproof protective coating.

The same type of lamp with protective coating must be used if replaced.

Sign off on the lamp replacement procedure

DANGER! BEFORE SERVICING! ALWAYS DISCONNECT ELECTRICAL POWER AT THE MAIN DISCONNECT WHEN SERVICING OR REPLACING ANY ELECTRICAL COMPONENT. This includes (but not limited to) Fans, Heaters Thermostats, and Lights.

The evaporator fans are located at the center front of these merchandisers directly beneath the display pans.

Should fans or blades need servicing, always replace fan blades with the raised embossed side of the blade TOWARD THE MOTOR.

Upload a photo of the replaced fan

Sign off on the fan maintenance
