Hussmann Merchandiser E2SP-RRS

Warning: This procedure requires trained personnel with PPE!

Drill with a 2 in. (51 mm) hole saw used to drill out the bottom of the drain fitting

Drilled completely through fitting and bottom liner

Coupling inserted into drain fitting without applying PVC or ABS pipe sealer

PVC adapter installed on the drip trap

Primer-sealer applied to a stub piece of PVC pipe and inserted between coupling and adapter

Sign off on the drain fitting replacement

Warning: Always use non-abrasive cleaning materials and polish with grain of the steel.

Used warm water or added a mild detergent to the water and applied with a cloth?

Select the type of cleaner used

Did you avoid cleaners containing salts?

Cleaned frequently to avoid build-up of hard, stubborn stains?

Used a stainless steel cleaning solution periodically to minimize scratching and remove stains?

Rinsed and wiped dry immediately after cleaning?

Warning: LOCK OUT / TAG OUT — To avoid serious injury or death from electrical shock, always disconnect the electrical power at the main disconnect when servicing or replacing any electrical component. This includes, but is not limited to, such items as doors, lights, fans, heaters, and thermostats.

Disconnect fan from wiring harness

Lift fan plenum and remove screws holding bottom of motor to fan basket

Reconnect fan to wiring harness

• Honeycombs should be cleaned every six months. Dirty honeycombs will cause merchandisers to perform poorly. The honeycombs may be cleaned with a vacuum cleaner. Soap and water may be used if all water is removed from the honeycomb cells before replacing. Be careful not to damage the honeycombs.

1. Using a flat object such as a screw driver, compress the honeycomb and remove it from its retainer.

2. Clean and dry the honeycomb.

3. After cleaning, replace in reverse order.

• The interior back panels may be removed for cleaning and to gain access to the evaporator coils. Remove the rear interior back panels as follows:

1. Disconnect the electrical power to the merchandiser.

3. Remove the lower panel first: lift the panel up, then pull forward and out.

• Long life and satisfactory performance of any equipment is dependent upon the care it receives. To ensure long life, proper sanitation and minimum maintenance costs, these merchandisers should be thoroughly cleaned, all debris removed and the interiors washed down, weekly.

• To facilitate cleaning, the fan plenum is hinged. After cleaning be sure the plenum is properly lowered into position or product loss will result due to improper refrigeration.

WARNING! PREVENT INJURY. ALWAYS SHUT OFF POWER DURING CLEANING PROCESS.

• The exterior surfaces must be cleaned with a mild detergent and warm water to protect and maintain their attractive finish. Never use abrasive cleansers or scouring pads.

• The interior surfaces may be cleaned with most domestic detergents, ammonia based cleaners and sanitizing solutions with no harm to the surface.
