Graco Spray Package 24V877
Need answers fast?
Explore the manual using AI.
The Graco Spray Package 24V877 is a high-performance industrial spray system designed for efficient fluid application. Known for its reliability and precision, this OEM asset is ideal for various coating and painting tasks in industrial settings. Optimize your operations with the Graco Spray Package's advanced features and robust construction.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Graco Spray Package 24V877
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Graco Spray Package 24V877
Create an account to install this asset package.
Maintenance Plans for Graco Spray Package Model 24V877
Integrate maintenance plans directly into your work orders in MaintainX.
1 Daily Wet Cup Inspection
Wet Cup Maintenance
Fill the wet cup one-half full with Graco Throat Seal Liquid (TSL)
Is the wet cup filled one-half full with Graco Throat Seal Liquid (TSL)?
Daily Maintenance
Is the level maintained daily?
Sign off on the daily wet cup inspection
Spray Package Maintenance
Care of the Pump
NOTICE: Do not allow the supply containers to run dry of the fluid being pumped.
Supply container is not dry
Throat packing reservoirs one-half filled with TSL
Pot life limit observed
System flushed when necessary
Fluid manufacturer’s instructions for fluid shelf life followed
System flushed with a compatible solvent
Pump flushed at higher cycle rates for heavy fluids
1 Daily Manual Lubrication
Warning: Disconnect the regulator before proceeding.
Regulator disconnected?
Place about 15 drops of light machine oil in the motor air inlet.
Oil placed in the motor air inlet?
Reconnect the regulator.
Regulator reconnected?
Turn on the air supply to blow oil into the motor.
Air supply turned on?
Sign off on the daily manual lubrication
Unlock efficiency
with MaintainX CoPilot
MaintainX CoPilot is your expert colleague, on call 24/7, helping your team find the answers they need to keep equipment running.
