Graco Pump System 24F094

Graco Pump System 24F094

Create an account to install this asset package.

Maintenance Plans for Graco Pump System Model 24F094

Integrate maintenance plans directly into your work orders in MaintainX.

Pump Maintenance

Check mark

Displacement Pump Removal

Check mark

Pressure relief procedure followed

Check mark

Upload a photo of the disconnected fluid line from the pump outlet

Check mark

Tie rod shield (26) or coupler shield (79) removed

Check mark

Coupling nut (16) loosened

Check mark

Coupling collars (15) and coupling nut (16) removed

Check mark

TSL reservoir (25) removed

Check mark

Tie rod nuts (14) removed

Check mark

Displacement pump removed with the pump adapter attached

Run this procedureArrow right

Fluid Controls Maintenance

Check mark

Before Servicing

Check mark

Meter-based systems: Remove Air/Fluid Panel

Check mark

Pump-based systems: Remove fluid inlet hose, fluid outlet pressure sensor, fluid fitting, fluid outlet lines, solvent supply hose

Check mark

Meter-based systems: Disconnect fluid inlet lines from valve stacks

Check mark

Remove four bolts and washers from inside the panel to remove each valve stack

Check mark

3-Color System: Remove four bolts from top of valve stack. Separate the two manifolds

Check mark

Replace Seat(s): Remove dosing valve from manifold, then remove and replace seat and o-rings

Check mark

Service Dosing Valve: Follow all instructions and warnings in manual 312782 to rebuild the dosing valve

Check mark

Valve Manifold Rebuild: For full service of your valve stack, follow directions in Dosing Valve Manifold Rebuild

Run this procedureArrow right

Solenoid Replacement

Check mark

The system has a minimum of 4 solenoids. If you have a 3-color system or a gun flush box, you have additional (optional) solenoids for each.

Check mark

⚠️⚡️

Check mark

To replace a single solenoid:

Check mark

1. Follow Before Servicing, page 13. Disconnect main power.

Check mark

2. Open Control Box.

Check mark

3. Disconnect 2 solenoid wires (N) from harness (320). See FIG. 3.

Check mark

4. Unscrew 2 screws (P) and remove solenoid (306).

Check mark

5. Install new solenoid (306).

Check mark

6. Connect 2 wires (N) to harness (320). Solenoid wires are polarized (red+, black-). Refer to System Electrical Schematics, pages 54–57.

Run this procedureArrow right

Alarm Replacement

Check mark

Follow Before Servicing, page 13. Disconnect main power.

Check mark

Control Box opened

Check mark

Alarm wires disconnected from alarm (311)

Check mark

Alarm jam/mounting nut unscrewed and alarm removed

Check mark

New alarm assembled and alarm wires reconnected

Check mark

Control Box closed and power restored

Run this procedureArrow right

Display Module Replacement

Check mark

Follow Before Servicing, page 13

Check mark

Display Module (63) removed from the mounting bracket (49)

Check mark

CAN cable (64) disconnected

Check mark

New Display Module replaced

Check mark

CAN cable (64) reconnected

Check mark

Follow instructions in Manual 3A1244 to update the software on the new Display Module

Check mark

Sign off on the Display Module Replacement

Run this procedureArrow right
