Genie Electric Scissors SJIII 3219

Raise the platform (refer to Section 3.8-2) until there is adequate clearance to swing down the maintenance support (refer to Section 3.12)

Ensure maintenance support is properly secured and shows no visible damage

Ensure scissor assembly shows no visible damage and no signs of deformation in weldments

Ensure all pins are properly secured

Ensure cables and wires are properly routed and shows no signs of wear and/or physical damage

Ensure bumpers are secure and shows no sign of visible damage

Ensure rollers are secure and there is no visible damage

Ensure rollers' path of travel are free from dirt and obstructions

Ensure each lift cylinder is properly secured, there are no loose or missing parts and there is no evidence of damage

WARNING: To avoid injury, do not operate an aerial platform until all malfunctions have been corrected.

WARNING: To avoid possible injury, ensure aerial platform power is off during your visual and daily maintenance inspections.

CAUTION: Ensure aerial platform is on a firm, level surface.

NOTE: While performing visual and daily inspections in different areas, be aware to also inspect limit switches, electrical and hydraulic components.

Visual inspection of hoses and fittings

Visual inspection of all hydraulic cylinders

Visual inspection of all hydraulic manifolds

Visual inspection of the underside of the base ground area under the aerial platform

Report any malfunctions found during the inspection

This section provides the operator with the Winching and Towing procedure, which includes instructions on how to manually release the brakes

Ensure platform is fully lowered before winching or towing

Sudden motion could cause the aerial platform to become unstable

Death or serious injury could result

In emergency situations where aerial platform functions are not available and lowering is impeded by an obstacle, utmost care must be taken to move aerial platform far enough to clear the obstacle

In such cases, operation must be extremely smooth with no sudden movements and must not exceed a speed of 2"/sec (50 mm/sec)

WARNING: To avoid injury, do not operate an aerial platform until all malfunctions have been corrected.

WARNING: To avoid possible injury, ensure aerial platform power is off during your visual and daily maintenance inspections.

CAUTION: Ensure aerial platform is on a firm, level surface.

NOTE: While performing visual and daily inspections in different areas, be aware to also inspect limit switches, electrical and hydraulic components.

Main Power Disconnect Switch: Turn main power disconnect switch to 'O' off position. Ensure all cables are secure and switch is in proper working condition.

Base Control Switches: Ensure there are no signs of visible damage and all switches are in their neutral positions.

Free-wheeling Valve Knob (SJIll 3219 - Front Side): Ensure there are no loose or missing parts and there is no visible damage.

Brakes: Ensure there are no loose or missing parts and there is no visible damage. Ensure tabs are not locked.

110V Outlet Receptacle: Ensure receptacle is free from dirt and obstructions.

WARNING: Explosion Hazard - Keep flames and sparks away. Do not smoke near batteries.

WARNING: Battery acid is extremely corrosive - Wear proper eye and facial protection as well as appropriate protective clothing.

Main power disconnect switch in 'O' off position?

Battery fluid level in each battery (should be at least 1/2'' or 13mm)

Battery terminals and cable ends cleaned thoroughly?

All battery connections are tight?

Any battery that is damaged or incapable of holding a lasting charge replaced?

WARNING: Use original or equivalent to the original parts and components for the aerial platform.
