Finish Thompson Container Pump Tube TBP-27

Insert the shaft assembly through the tube

Align and press the bearing assembly

Inspect components for damage and replace as needed

Inspect the bearing assembly for issues

Inspect the pump shaft for excessive wear

Loosen the setscrew and remove the half coupling (item 2) from the end of the pump shaft.

Gently hold the intake tube and use a 3/8” punch and hammer to drive the bottom of the shaft (item 11) toward the top until the bearing assembly (item 3) is exposed.

Use a 1/8” punch to drive out the roll pin in the center of the bearing assembly (item 3) and slide the bearing assembly off of the shaft.

Remove the pump shaft assembly by pushing it down through the intake tube (item 7) and out the bottom.

Remove and discard the seal assembly (item 4). Never re-use a seal assembly.

Ensure all parts are removed and accounted for

Is the intake tube undamaged after disassembly?
