Daikin Indoor Unit Cooling Only Air Conditioner FTKS28JV2S

Create an account to install this asset package.

Maintenance Plans for Daikin Indoor Unit Cooling Only Air Conditioner Model FTKS28JV2S

Integrate maintenance plans directly into your work orders in MaintainX.

Swing Motor Removal

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Caution: When reassembling, do not confuse the installing order of the 2 motors for horizontal blades and the colors of the connectors.

If you set the connectors or motors opposite, the horizontal blades do not move smoothly or noise may be heard

1. Remove the swing motors for horizontal blades.

1) Hold the indoor unit up with a piece of wood.

2) Remove the screw at the rear of the indoor unit.

3) Remove the 2 screws.

4) Release the interlock rod.

5) Remove the swing motor unit.

Run this procedure

Horizontal Blade Removal

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

1. Remove the horizontal blades.

1) Release the right shaft of the horizontal blade (large).

2) Release the left shaft.

3) Release the inner right shaft.

4) Release the inner left shaft.

5) Remove the horizontal blade (large).

6) Remove the horizontal blade (small) in the same way.

2. Remove the air outlet ASSYs.

Run this procedure

Electrical Box Removal

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the screw

Remove the drip proof plate from the indoor heat exchanger

Remove the screw and release the earth/ground wire

Pull out the indoor heat exchanger thermistor

Remove the screw, and then the wire fixture

Remove the 4 screws on the terminal strip and disconnect the connecting wire

Disconnect the connector [S1] and release the harness from the hook

Release the ferrite core

Run this procedure

Air Filter / Front Panel Removal

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

1. Remove the air filters.

The 3 filters are interchangeable.

Insert the air filter with the "FRONT" mark faced up.

The air filter can be set easily by inserting it along the guides.

Be sure to insert the 2 lower hooks when reassembling the air filter.

1) Open the front panel to the position where it stops.

2) Pull out the air filter downward and remove it.

2. Remove the Titanium apatite deodorizing filters.

Run this procedure

Indoor Heat Exchanger Removal

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

In pump-down work, be sure to stop the compressor before disconnecting the refrigerant pipe. If the refrigerant pipe is disconnected with the compressor operating and the stop valve open, air may be sucked in and may generate an over-pressure in refrigeration cycle, thus resulting in pipe rupture or accidental injury.

When removing or reinstalling the indoor heat exchanger, be sure to wear gloves or wrap the indoor heat exchanger with cloths. (You may be injured by the fins.)

Caution: Be sure to conduct pump down operation before disassembling the refrigerant pipe.

If the refrigerant leaks, repair the spot of leaking, then collect all refrigerant from the unit. After conducting vacuum drying, recharge proper amount of refrigerant.

From the viewpoint of global environmental protection, make sure to use a vacuum pump for air purging.

Pull out and disconnect the drain hose.

Wrap the open ends of the drain hose with plastic sheets to prevent water dripping.

Unscrew the flare nuts for gas piping and liquid piping.

Run this procedure
