Daikin Cooling-Only Outdoor Unit RKS50JVMG

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Warning: Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine.

Warning: If the refrigerant gas leaks during work, ventilate the room. (If the refrigerant gas is exposed to flames, toxic gas may be generated.)

Warning: Since it may happen that the refrigerant oil in the compressor catches fire, prepare wet cloth so as to extinguish fire immediately.

Caution: From the viewpoint of global environment protection, do not discharge the refrigerant gas in the atmosphere. Make sure to collect all the refrigerant gas.

Caution: Restore the piping by non-oxidation brazing.

Note: Before working, make sure that the refrigerant gas is empty in the circuit.

Note: Be sure to apply nitrogen replacement when heating up the brazed part.

Note: Do not use a metal saw for cutting pipes by all means because the sawdust comes into the circuit.

Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine.

If the refrigerant gas leaks during work, ventilate the room. (If the refrigerant gas is exposed to flames, toxic gas may be generated.)

From the viewpoint of global environment protection, do not discharge the refrigerant gas in the atmosphere. Make sure to collect all the refrigerant gas.

1. Restore the piping by non-oxidation brazing.

2. It is required to prevent the carbonization of the oil inside the four way valve and the deterioration of the gaskets affected by heat. (Keep below 120°C (248°F).) For the sake of this, wrap the four way valve with wet cloth and provide water so that the cloth does not dry.

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Release the clamp from the partition plate

Release the fan motor lead wire from the groove and the 2 hooks of the partition plate

Remove the nut and remove the outdoor fan

Remove the 2 screws of the fan motor fixing frame

Pull up the fan motor fixing frame to unfasten the 2 hooks at the bottom

Remove the fan motor fixing frame

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the 2 screws and remove the protection plate.

Remove the 3 screws and remove the wire fixture.

Remove the 7 screws and remove the connecting wire and the power supply wire.

Remove the 2 screws and remove the earth / ground wire.

Pull out the outdoor temperature thermistor.

Remove the 4 screws of the right side panel.

Unfasten the 3 hooks and remove the right side panel.

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the 2 screws and remove the partition plate.

Remove the sound blanket (top upper).

The design of the sound blankets varies depending on the model.

Remove the sound blanket (top lower).

Remove the sound blanket (back).

Remove the sound blanket (outer).

Since the piping ports are torn easily, remove the sound blankets carefully.

Remove the sound blanket (inner).
