Bombardier Recreational Products Vehicle 1200 4-TEC

WARNING: The engine oil can be very hot. Wait until engine oil is warm.

NOTICE: Engine oil and oil filter must be replaced at the same time.

Place vehicle on a level surface.

From underneath the vehicle, access the drain plug.

From underneath vehicle, clean drain plug area.

Place a drain pan under frame opening.

Access to Chaincase Open RH side panel.

2. Unscrew tensioner lock nut several turns.

3. Unscrew tensioner adjustment screw a few turns.

5. Clean adjustment screw threads if necessary.

NOTICE Adjustment screw threads must be clean to obtain an accurate adjustment.

Warning: Operating the engine with an improper oil level may severely damage engine. Wipe off any spillage.

Make sure the engine is at normal operating temperature. The engine reaches its normal operating temperature when the rear radiator gets warm.

Place vehicle on a level surface.

Let engine run at idle for approximately 30 seconds.

Remove dipstick from the filler tube, then wipe it clean.

Completely insert dipstick in the filler tube.

Remove dipstick and check the oil level.

Air Filter with Dual Air Intake

There are two air intake pre-filters, one on each side of the console.

Ensure the air intake prefilters are properly installed, clean and in good condition.

If the air filter has to be cleaned or replaced, see an authorized Ski-Doo dealer, repair shop or person of your own choosing.

Never open coolant tank cap when engine is hot.

Engine Coolant level Verification

WARNING: The engine oil can be very hot. Wait until engine oil is warm.

NOTICE: Engine oil and oil filter must be replaced at the same time.

Vehicle placed on a level surface

Access cover retaining screw removed and the other loosened

Access cover pivoted to clear the bottom pan opening

Drain plug area cleaned from underneath vehicle
