Bobcat Loader 863F

Empty spark chamber. (If equipped Spark Arrestor Muffler.)

Check battery for damage, hold down clamps, cables, connections and electrolyte level. Add distilled water as needed

Lubricate drive line Engine-to-Pump Coupler with multipurpose lithium based grease. (If equipped.)

Sign off on the loader maintenance

Replaced fluid on Hydraulic Reservoir

Replaced fluid on Final Drive Transmission (Chaincase On Wheel Machines Only)

Replaced fluid (If required) in Track Roller, Idler Assemblies (Track Machines Only)

Replaced Drive Motor Case Drain Filter (If equipped)

Repacked wheel bearings, greased internal splines in hub yoke. (Dealer Service Only) Wheel Bearing & Outer Splines (Aws Only)

Sign off on the 1000 Hours Loader Maintenance

Hydraulic system filter replaced

Hydrostatic system filter replaced

Reservoir breather cap replaced

Steering Valve Inline Filter replaced (AWS Only)

Oil in Hydrostatic Motor Carrier replaced (Track Machines Only)

Sign off on the 500 Hours Loader Maintenance

Steering Lever Pivots lubricated with multipurpose lithium based grease?

King Pins lubricated with multipurpose lithium based grease (Aws Machines Only)?

Engine / Hydraulic Drive Belt checked for wear or damage?

Fan Drive Gearbox fluid level checked and added if required?

Condition and tension of Other Drive Belts (Hydrostatic pump, water pump, alternator, and air conditioner - if equipped) checked?

Function of Lift Arm By-Pass control in BISC checked?

Sign off on the 250 Hours Loader Maintenance

NOTE: The following steps are to be performed before starting the loader.

Change oil and filter after first 50 Hrs

Condition of engine air filter indicator and/or display is good?

Service only when required. Do not use compressed air to clean elements.

Any leaks or damaged components in the engine air system?

Is the grill, oil cooler and radiator of engine cooling system clean from debris?
