Advantage Temperature Control Unit SK-1065

Disengage operations and ensure all system pressure is relieved

Verify the unit's pressure gauges read "0"

Verify the Power light on the display is "off"

Remove the lift-off access panel and set aside

Drain machine by removing the pump casing drain plug

Reduce process water temperature to below 85°F.

Verify all system pressure is relieved and the pressure gauges read "0".

Verify the Power light on the display is "off".

Remove the lift-off access panel to access the cooling cylinder.

Disengage process operations and verify all system pressure is relieved and the unit's pressure gauges read '0'.

Disengage main power supply and verify the Power light on the display is 'off'.

Remove the 'To Process' temperature probe and insert a 1/2" plug in its place.

Record the temperature of the ice water bath using an accurate digital thermometer.

Familiarize with the manual and operating characteristics of the equipment

Ensure proper operator training, installation, operation, and maintenance

Follow safety considerations and lock-out procedures

Is the system pressure eliminated and pressure gauges read '0'?

Shut down unit operations according to section 3.4

Drain unit by removing the pump casing drain plug

Remove the capillary connection from the cooling cylinder to the pressure switch

Disengage process operations and verify all system pressure is relieved and the unit's pressure gauges read '0'.

Disengage main power supply and verify the Power light on the display is 'off'.

Remove the lift-off access panel and set aside.

Disconnect the valve wiring harness.

Remove the AVT valve's drip cover.

Remove the 2 mounting screws securing the motor/gearbox assembly to the valve bracket.

Remove the 2 screws securing the micro switch to completely remove the motor.
