Adolf Mohr Maschinenfabrik High-Speed Paper Cutter 115 ED

Ensure the machine is turned off and cooled down

Gather necessary tools and equipment

Check for any leaks around the oil drain plug

Place an oil pan under the drain plug

Carefully remove the oil drain plug to bleed hot oil

Replace and tighten the oil drain plug

Warning: Attention when bleeding hot oil - danger of burning!

Ensure the machine is turned off and cooled down

Gather necessary tools and equipment

Locate the hydraulic unit inside the right frame pillar

Place a container to collect old oil

Bleed the hot oil carefully to avoid burns

Dispose of the old oil according to environmental regulations

BACKGAUGE GUIDE RAILS (only 78, 92, 115, 137, 155)

Ensure the machine is turned off and secured

Locate the 2 lubricating nipples on the backgauge

Enter the number of strokes used with the grease gun

Was the lubrication completed successfully?

Clean any excess grease from the area

Warning: Attention when bleeding hot oil - danger of burning!

Ensure hydraulic unit is mounted inside right frame pillar

Record the current operating hours of the machine

Has the oil been changed within the last 6000 hours?

Change the oil if it has not been changed within the last 6000 hours

Ensure the machine is turned off and cooled down

Gather necessary tools and materials (grease gun, grease)

Apply 2-3 strokes of grease to each lubrication point

Is there any excess grease that needs to be wiped off?

Clean the grease gun and store it properly
