Sullair Vacuum System VS32-150/A

Air filter maintenance should be performed every six (6) months or when indicated by the inlet vacuum gauges.

Clean exterior of air filter housing.

Remove the air filter cover by loosening the clamps securing the cover.

Clean debris from inside filter housing prior to removing element.

Remove element and clean the base and interior of cover using a damp cloth. DO NOT blow dirt out with compressed air.

At this time, replace the element.

Sign off on the air filter maintenance

Warning: Only use a replacement fluid filter identified with the Sullair name, logo and appropriate part number.

Old element and gasket removed with a strap wrench?

Gasket seating surface cleaned?

Light film of fluid applied to the new gasket?

New element hand tightened until new gasket is seated in the gasket groove without any nicks, cuts or pinches?

Element tightened by hand an additional 1/2 to 3/4 turn?

Vacuum restarted and checked for leaks?

Sign off on the fluid filter maintenance

Warning: This procedure requires trained personnel with PPE!

Relieved all pressure from the sump tank?

Disconnected all piping connected to the sump cover?

Loosened and removed the capscrews from the cover plate?

Lifted the cover plate from the sump?

Inspected the receiver/sump tank for rust, dirt, etc.?

Scraped the old gasket material from the cover and the flange on the sump?

Inserted new the separator element into the sump without denting it?

Warning: This procedure requires trained personnel!

Enter the current operating vacuum

Is the operating vacuum at 20 in-Hg (508mm)?

If not, adjust the vacuum regulator

Is the jam nut on the vacuum regulator loose?

Did you adjust the screw clockwise to increase the setting or counterclockwise to decrease the setting?

Is the new operating vacuum at 20 in-Hg (508mm)?

Warning: Drainage and fill-up of lubricant from the cooler core must be done separately from the separator tank; the thermal valve isolates the connecting pipework. Please use the provided filler (outlet manifold), drain (outlet manifold) and breather (inlet manifold) plugs for these tasks.

Cleaned the return line strainer?

Lubricated the Sullicon Control linkage?

Drained the sump and changed the vacuum pump fluid?

Sign off on the 4000 Hourly Vacuum System Maintenance
