Novexx Solutions Label Printer ALX 924

Unplug the mains power connecting line.

Remove the label material and ribbon.

Remove both wing bolts until the printhead can be swivelled up.

Screw out the thumb screw [71A]

Take off the locking plate [71B]

Pull the deviator roller off its axle [72]

Remove the mains power connecting line

Pull out both plugs on the printhead [66]

Remove both wing bolts until the entire printhead can be removed from the pressure shaft

Install the new printhead at the former position and retighten the wing bolts

Ensure the machine is powered off

Wear appropriate personal protective equipment (PPE)

Clean the following parts that come into contact with the ribbon

Inspect the ribbon path for any residue or debris

Is additional cleaning required?

Verify all parts are dry and free of cleaning agents

Remove the mains power connecting line

Remove the bolts [73A] using 3 mm Allen key

Remove guide section [73A] from side

Write down the position of the sensor thumb wheel [74B]
