Electrolux Vacuum Cleaner 4760AZ

Motor Filter Inspection and Cleaning

Check the motor filter with each disposable dust bag change

Remove filter from inside bag compartment, at bottom

Shake filter to remove excess dust

Clean the filter by laundering with warm water if necessary

Ensure the motor filter is completely dry before re-installing

Re-install the motor filter prior to next use

Confirm the motor filter is properly in place before using the vacuum

Remove hose from hose retainer on the base

Check suction at end of hose - is there little or no suction?

Check and empty dust bag if needed

Remove electrical cord from cord hooks

Unscrew the two screws on the side of the Turbo Nozzle

Clear blockage from brush roll area

Have a Phillips screwdriver available

Assemble the rear housing to the base using a long screw (FIG. 1)

Attach the tool caddy to the rear housing using 2 short screws (FIG. 2)

Attach the handle to the tool caddy using a long screw (FIG. 3)

Secure the hose assembly to the rear housing with 2 short screws (FIG. 4)

Thread the hose inside the lower hose retainer and attach it to the rear housing with a short screw (FIG. 5)

Contact customer service to replace light bulb

Lower handle and remove two screws from lens cover

Support socket with one hand and pull light bulb straight out to release

Place new light bulb into socket; push to secure
