Nordson Dispensing Workstation Ultra 2405
Create an account to install this asset package.
Maintenance Plans for Nordson Dispensing Workstation Model Ultra 2405
Integrate maintenance plans directly into your work orders in MaintainX.
Dispensing Workstation Teach Mode Test
Setup for Testing
Upload a photo of the EFD syringe barrel attached to the adapter assembly
Enter the vacuum set value
Upload a photo of the EFD precision dispense tip replacing the orange tip cap
Upload a photo of the syringe barrel snapped in place in the hand grip
Testing in Teach Mode
Did you successfully purge your dispensing tip with fluid?
Did you successfully change to TEACH mode?
Upload a photo of the dispense tip resting on the Dot Standards sheet
Dispensing Workstation Steady Mode Test
Setup for Testing
Upload a photo of the EFD syringe barrel attached to the adapter assembly
Enter the vacuum set value
Upload a photo of the EFD precision dispense tip replacing the orange tip cap
Upload a photo of the syringe barrel snapped in place in the hand grip
Testing in Steady Mode
Select the mode
Enter the air pressure regulator knob value
Did the fluid begin to dispense out of the tip in a controlled flow?
Dispensing Workstation Timed Mode Test
Setup for Testing
Attach an EFD syringe barrel filled with your assembly fluid to the adapter assembly
Keep the vacuum set at 0.0 during initial testing
Replace the orange tip cap with an EFD precision dispense tip
Slide the syringe barrel into the hand grip. Snap in place
Testing in Timed Mode
Follow steps in “Testing in Steady Mode” to purge your dispensing tip with fluid
Change to TIMED mode
Set time to 000.0250 seconds
Parts for Nordson Dispensing Workstation Ultra 2405
Access the parts list for your equipment in MaintainX.
Cleanroom Filter Muffler
2400FT
Five-Micron Filter Regulator
2000F755
Vacuum Suck-Back Filter Trap
2435
Pin Male Connector Assembly
2446
Tubing, 6 MM OD Urethane, Blue
2024-6MM
Cleanroom Filter Muffler
2400FT
Five-Micron Filter Regulator
2000F755
Vacuum Suck-Back Filter Trap
2435
Pin Male Connector Assembly
2446
Tubing, 6 MM OD Urethane, Blue
2024-6MM
Cleanroom Filter Muffler
2400FT
Five-Micron Filter Regulator
2000F755
Vacuum Suck-Back Filter Trap
2435
Pin Male Connector Assembly
2446
Tubing, 6 MM OD Urethane, Blue
2024-6MM
