The Miller Engine Driven Air Compressor Bobcat 200 is a robust and reliable portable compressor designed for various industrial applications. Known for its durability and efficiency, this model provides consistent air pressure and is ideal for construction and maintenance tasks. Experience high performance with the Bobcat 200 in your operations.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Miller Engine Driven Air Compressor Bobcat 200

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

Miller Engine Driven Air Compressor Bobcat 200

Create an account to install this asset package.

Maintenance Plans for Miller Engine Driven Air Compressor Model Bobcat 200

Integrate maintenance plans directly into your work orders in MaintainX.

1000 Hourly Engine Driven Welder Maintenance

Check Slip Rings

Clean Slip Rings

Check Brushes

Replace Brushes

Clean Inside Unit

Replace Air/Oil Separator

Run this procedure

2000 Hourly Engine Driven Welder Maintenance

Check Fuel Hoses

Replace Fuel Hoses

Replace Compressor Fan Belt

Sign off on the maintenance

Run this procedure

500 Hourly / 1 Yearly Engine Driven Welder Maintenance

WARNING: Do not open oil fill cap until unit has been off for 10 minutes the air compressor gauge reads zero. Do not open while running.

WARNING: Do not run air compressor without air cleaner or with dirty element. Compressor damage caused by using a damaged element is not covered by the warranty.

Check Compressor Oil

Replace Compressor Oil Filter

Check Air & Control Lines For Wear & Aging

Check Compressor Belt Condition/Tension

Check Weld Cables

Replace Weld Cables

Change Spark Plugs

Run this procedure

250 Hourly Engine Driven Welder Maintenance

Stop engine. NOTICE − Do not run engine without air cleaner or with dirty element. Engine damage caused by using a damaged element is not covered by the warranty.

Maintenance Tasks

Precleaner Maintenance

Wash precleaner with soap and water solution. Allow precleaner to air dry completely. Spread 1 tablespoon SAE 30 oil evenly into precleaner. Squeeze out excess oil.

Element Maintenance

Replace element if damaged, dirty, or oily.

Sign off on the maintenance tasks

Run this procedure

Overload Protection

Stop engine.

When a circuit breaker, supple-mentary protector or fuse opens, it usually indicates a more serious problem exists. Contact a Factory Authorized Service Agent.

1 Supplementary Protector CB1

CB1 is located on the front panel and protects the auxiliary power receptacles and weld/battery charge module from overload. If CB1 opens, none of the AC receptacles or weld/battery charge functions will work. Place switch in On position to reset.

2 Supplementary Protector CB2

CB2 is located on the front panel and protects 120V receptacle RC2 from overload. If CB2 opens, RC2 will not work. Press button to reset.

3 Supplementary Protector

CB3 CB3 is located on the front panel and protects 120V receptacle RC3 from overload. If CB3 opens, RC3 will not work. Press button to reset.

4 Fuse/Relay Module Label
