Life Fitness Gym Equipment HDU-PSF

Inspect insert within the strain-relief cable end assembly for any sign of damage

Check around plastic insert and the plastic housing for any excessive wear or damage

Replace plastic insert if cracked, torn, separated, overly worn or damaged in any way

Verify technician is Life Fitness certified

Ensure cable is threaded at least 1/2 inch (12.7mm) into termination points at headplate (A) and frame/carriage (B)

Check if model is equipped with a bayonet portal for thread engagement verification

Attempt to pass a 7mm Allen wrench through the bayonet portal to check thread engagement

Tighten jam nut to 20-25 FT-LBS (27.2 - 34.0 Nm) using a 24mm wrench when proper thread engagement is reached

Check if cable tension is sufficient to keep it seated in the pulley without lifting the head plate

Loosen jam nuts and threaded plugs if head plate is lifted, until it rests on the weight plate below

Apply polishing compound (e.g., car wax) to frame

Remove shoe scuffs from powder coated surfaces as necessary

Inspect hardware on all machines

Tighten any bolts or nuts that may have loosened over the life of the product

Inspect all accessories, connecting links, and carabiner clips

Check anchors and re-tighten to 30 Foot-Pounds (45Nm) if needed

Clean upholstery with an approved or compatible cleaner

Approved and Compatible Cleaners

Select approved cleaner for use

Apply cleaner to a microfiber cloth before cleaning

Ensure PureGreen 24 is used for at least 2 minutes for general disinfection
