Komatsu Forklift Truck FG15T-20

1. Connect the timing advance tester (1) as shown inthe diagram on the right.

2. Turn the power switch on and adjust the timing position of the advance adjustment knob (2).

3. Start the engine and run at the specified idling speed.

4. Glow the timing light (3) and check to make sure that the indicator and the timing mark stamped on the crankshaft pulley and flywheel are correctly aligned.

5. If the timing is wrong, turn the distributor (4) to the right or the left for further adjustment.

6. Check that ignition timing advances quickly when the engine is revved up.;

WARNING: Before starting maintenance of the engine, stop the engine and wait until cooling down completely

1) Remove the cartridge with the filter wrench.

2) Clean the filter mounting up and apply the engine oil to the thread as well as the seal of the new cartridge before installation.

After installing the cartridge, start the engine and check to make sure that there is no oil leakage from the filter mounting surface.;

WARNING: The temperature of the oil is very high immediately after stop operation of the truck. Be sure to start inspection after cooling down completely.

1. Remove the drain plug located at the bottom of the hydraulic tank for draining. Then, uncover the hydraulic tank and remove the strainer. Clean the strainer up with flushing oil.

2. After cleaning inside hydraulic tank, install the drain plug.

3. After cleaning the strainer, blow dry compressed air from inside to outside of the strainer until it is completely dry.

4. Remove the line filter and replace it with a new one. Then, install the tank cover.

5. Refill the hydraulic oil through the breather hole. Check the oil level with the oil level gauge.

6. Start the engine and operate the mast with lifting and tilting until stroke-end for several times so as to bleed the air.

IMPORTANT: Always be sure to use the Komatsu genuine hydraulic oil.;

For operation safety, never fail to perform periodic maintenance or make periodic replacement of the consumable parts listed in the following.

These parts may deteriorate in time and are susceptible to wear. It is difficult to estimate the degree of wear at time of periodic maintenance; therefore, even if no apparent wear is found, always replace with new parts within the prescribed period of replacement (or earlier if trouble is found).

Note that periodic replacement has nothing to do with guarantee service.

Replace Reservior tank and tube

Replace Stop lamp switch (Oil pressure type)

Replace Rubber parts of power steering

WARNING: The temperature of the oil is very high immediately after stop operation of the truck. Be sure to start inspection after cooling down completely

1. Open the floor plate to check the oil level with the oil level gauge.

2. Refill the oil if necessary.;
