John Deere Tractor 3033R

Warning: This maintenance check requires trained personnel with PPE!

Engine valve clearance checked?

If engine valve clearance is not checked, report the issues to the maintenance team and stop the procedure

Choose the type of service done

Engine passed the post-maintenance test?

Sign off on the 1000 Hourly Maintenance

Check cab rollover protection system mounting hardware torque

Check windshield wiper arm mounting hardware torque

Park the machine safely. (See Parking Safely in Safety section.)

Remove dipstick (A), located at the right side of the engine. Wipe with a clean cloth.

Check oil level on dipstick. Oil level should be between levels (B) and (C) on dipstick.

If oil level is low: a. Raise hood. b. Remove right side panel. c. Remove oil fill cap (D). d. Add recommended engine oil until level is within operating range on dipstick. Do not overfill. e. Install dipstick.

If oil is above level (B) on dipstick, drain to proper level.

Check and adjust alternator belt

Machine parked safely and engine cooled?

Belt tension within specifications?

Adjusting bolt (B) and pivot bolt (C) loosened?

Outward pressure applied to alternator housing until tension is correct?

Place drain pan under the oil drain plug (A) on the underside of engine

Wipe dirt from around the oil filter (B)

Turn filter counterclockwise to remove

Put a light coat of clean engine oil on gasket of the new filter

Install replacement oil filter by turning filter clockwise until gasket contacts filter base. Tighten additional 1/2 turn

Install drain plug. Do not overtighten
