John Deere Compact Utility Tractor 3025E

Dipstick removed and wiped with a clean cloth

Drain, Flush and Refill Engine Cooling System

Slowly open radiator cap to the first stop to release all pressure

Position a pan under the radiator drain plug

Open the drain plug and allow the coolant to drain from the system

When coolant drains from the recovery tank, remove the radiator cap

Place drain pan under oil drain plug (A), under side of engine

Wipe dirt from around oil filter (B)

Turn filter counterclockwise to remove

Put a light coat of clean engine oil on gasket of new filter

Install replacement oil filter by turning filter clockwise until gasket contacts filter base. Tighten additional one half turn

Install drain plug. Do not overtighten

Run the engine a few minutes to warm the transmission oil

Position the drain pan under the transmission drain plug (A). Remove the plug and allow oil to drain completely

Position the drain pan under the hydraulic suction filter (B) and HST filter. Remove and discard the filter. Allow residual oil to drain completely

Put a film of clean transmission oil on the seal of the new filter

Fill the filter 1/3- 1/2 full of oil

Install the filter and turn clockwise until the gasket contacts the mounting surface. Tighten 1/2- 3/4 turn after gasket contact

Install and tighten the drain plug

Ensure the machine is parked safely on a level surface and has cooled down for at least one hour before starting the procedure.

If oil level is low, add recommended oil through dipstick fill opening until oil level is correct.

Check front axle oil level again after the first several hours of operation.

Lubricate lift link grease fitting with recommended grease or equivalent.

Lubricate ball joints and drawbar hitch with the SUPER LUBE® lubricant.

Lubricate grease points under normal conditions.

Sign off on the 50 Hourly Maintenance
