John Deere John Deere Combine Harvester 9570 STS 9570 STS

Cab Air Filter cleaned or replaced?

Note: Clean or replace Cab Recirculation Air Filter every 200 hours and as required.

Cab Recirculation Air Filter cleaned or replaced?

Replace after first 100 hours and then every 250 hours

Crank-case filled with seasonal viscosity grade oil or Torq-Gard SupremeTM?

Note: If using Plus-50TM oil and a John Deere filter, the service interval can be extended by 50 percent. Example: 250 hours extends to 375 hours.

Note: Change oil every 100 hours if fuel contains more than 0.5 % sulfur.

Sign off on the 50 Hourly Combine Maintenance

Engine air filter light stays ON?

If yes, replace both Primary and Secondary Filter

Note: Replace all three filters at a time. (Hydrostatic Pump / Engine Gearcase / Main Hydraulic Filter)

Hydrostatic Pump Filter replaced?

Sign off on the 400 Hourly Combine Maintenance
