Hussmann Low Temperature Self Contained Glass Door Merchandiser VRL2B

Power to the merchandiser disconnected

LED fixtures located and screws removed

LED fixture disconnected from the merchandiser

Power returned to the merchandiser

Sign off on the lamp replacement

As part of an ongoing maintenance program for Innovator Doors, Hussmann recommends that the items below be checked annually.

b) Gasket performance (check for tearing and proper sealing)

c) Check the top hinge pin to ensure the pin is properly seated and not bent

d) Check the bottom hinge plate for excessive wear (worn cam teeth)

e) Proper operation of hold open brackets

1. Check the doors for proper closing torque:

Test 1: Open door 90 degrees and close it manually. Make sure the door opens and closes without binding.

Test 2: Open door 90 degrees and release it. The door should close on its own.

Warning: Always turn off power to the case before working on any electrical components.

Upload a photo of the exposed frame heater

White portion of the heater not in contact with itself during installation

Only one white portion of the wire enters the raceway

Black lead wire enters the raceway

Resistance (ohm reading) after heater wire connection

To maintain peak operating efficiency, the coil should be cleaned at least once each month. A dirty coil slows product cooling significantly and increases energy consumption by as much as 20%. Dirt buildup on coils can also cause the compressor to lock up damaging the condenser unit.

All VRL models have the same access panel design for commonality between merchandisers.

Loosen screws at each side of the front bottom grille, then lift up and pull off the grille.

Detach the merchandiser’s electrical wire harness.

Unscrew the stop bracket that holds the condensing unit to the rail base.

Grab the condensing unit from condensing unit handle. Use only the unit handle to pull out the refrigeration system. Pulling on refrigeration lines or other parts will cause damage to the refrigeration unit.

Use a soft hand brush attachment on a vacuum to remove accumulated dust and debris.

Consult an authorized service technician if more extensive cleaning is needed. If the refrigeration unit is damaged, it can be replaced with a new unit.

Sign off on the condenser coils cleaning

Clean evaporator coil/s and fan blade/s. Do not use an acid base cleaner. Rinse off any cleaner residue.

Clean discharge air honeycombs or grilles. Do not use an acid base cleaner. Rinse off any cleaner residue.

Clean condenser coil/s and fan blade/s. Do not use an acid base Cleaner. Rinse off any cleaner residue.

Clean condensate drain pan and drain line.

Verify condensate drain lines are clear and functioning.

Record voltage reading at unit with unit off.

Record voltage reading with unit running.

Record defrost heater voltage and amp draw.
