Gardner Denver Air Compressor L50

Create an account to install this asset package.

Maintenance Plans for Gardner Denver Air Compressor Model L50

Integrate maintenance plans directly into your work orders in MaintainX.

36000 Hourly / 78 Monthly Compressor Maintenance

DANGER: Air/oil under pressure will cause severe personal injury or death.

CAUTION: Fire hazard and slip hazard! Do not spill any oil! Look for leaks! Immediately take care of any spilled oil!

NOTICE: Dispose of the oil filter cartridge properly - it is hazardous waste! Look for leaks!

Shut down the compressor, relieve the system of all pressure, disconnect, lockout and tagout the power supply to the compressor package before removing valves, caps, plugs, fittings, bolts and filters.

Switch off the screw compressor unit, secure it against an accidental restart and ensure that it is depressurized.

Wait at least 5 minutes until the oil has settled, i.e. until the air has bubbled out.

Unscrew the oil filter cartridge with a suitable tool

Dispose of the oil filter cartridge properly

Lightly oil the seal of the new oil filter cartridge

Run this procedure

36000 Hourly / 108 Monthly Compressor Maintenance

DANGER: Air/oil under pressure will cause severe personal injury or death.

CAUTION: Fire hazard and slip hazard! Do not spill any oil! Look for leaks! Immediately take care of any spilled oil!

NOTICE: Dispose of the oil filter cartridge properly - it is hazardous waste! Look for leaks!

Switch off the screw compressor unit, secure it against an accidental restart and ensure that it is depressurized.

Wait at least 5 minutes until the oil has settled, i.e. until the air has bubbled out.

Unscrew the oil filter cartridge with a suitable tool

Dispose of the oil filter cartridge properly

Lightly oil the seal of the new oil filter cartridge

Run this procedure

8 Hourly Compressor Check

Check air/oil reservoir oil level

Did you add oil?

Check operation of the machine, is it loading and unloading properly

Check discharge pressure

Check discharge temperature

Check control panel for advisory text messages

Sign off on the compressor check

Run this procedure

34000 Hourly / 102 Monthly Compressor Maintenance

Replace oil filter element

Change oil filter cartridge

DANGER

Air/oil under pressure will cause severe personal injury or death.

• Shut down the compressor, relieve the system of all pressure, disconnect, lockout and tagout the power supply to the compressor package before removing valves, caps, plugs, fittings, bolts and filters.

CAUTION

Fire hazard and slip hazard!

• Do not spill any oil!

• Look for leaks! Immediately take care of any spilled oil!

Run this procedure

8000 Hourly / 24 Monthly Compressor Inspection

DANGER: Air/oil under pressure will cause severe personal injury or death.

CAUTION: Fire hazard and slip hazard! Do not spill any oil! Look for leaks! Immediately take care of any spilled oil!

NOTICE: Dispose of the oil filter cartridge properly - it is hazardous waste! Look for leaks!

Switch off the screw compressor unit, secure it against an accidental restart and ensure that it is depressurized.

Wait at least 5 minutes until the oil has settled, i.e. until the air has bubbled out.

Unscrew the oil filter cartridge with a suitable tool
