Daikin Outdoor Heat Pump 3MKS58LVMA

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Remove the 2 screws and remove the fan motor fixing plate.

Fit the lower hooks when reassembling the fan motor fixing plate.

Remove the nut and remove the outdoor fan.

Align the mark of the outdoor fan with the D-cut section of the motor shaft when reassembling.

Put the fan motor lead wire through the back of the fan motor to avoid entanglement with the outdoor fan when reassembling.

Open the 2 hooks and release the fan motor lead wire.

Remove the 4 screws and remove the fan motor.

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Unfasten the hooks and remove the electrical box cover.

Detach the clamp and disconnect the connector [S70].

Release the fan motor core for the harness of [S70].

Disconnect the connectors for the electronic expansion valve coil.

Disconnect the connector [S40].

Wait for 10 minutes after turning off all power supplies before starting disassembly.

Ensure no contact with heated pipes and parts from the gas brazing machine.

Is the room ventilated in case of refrigerant gas leakage?

Collect all refrigerant gas to prevent atmospheric discharge.

Restore piping using non-oxidation brazing.

Ensure refrigerant gas is empty in the circuit.

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Remove the 4 screws of the top panel

Remove the 6 screws of the front panel

Unfasten the 4 hooks of the front panel

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Disconnect the connectors [S52] [S102] from the service monitor PCB

Unfasten the upper hook and remove the service monitor PCB

Remove the screw of the terminal board and open it

Disconnect the connectors for the terminal board on the right side

Disconnect the 2 connectors for the reactor on the left side

Remove the 3 screws of the main PCB
