Daikin Cooling-Only Outdoor Unit RKS50GVMV

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Protection Plate and Wire Fixture Removal

Remove the 2 screws and remove the protection plate.

Remove the 3 screws and remove the wire fixture.

Remove the 7 screws and remove the connecting wire and the power supply wire.

Remove the 2 screws and remove the earth / ground wire.

Pull out the outdoor temperature thermistor.

Remove the 4 screws of the right side panel.

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Remove the 2 screws and remove the partition plate.

Remove the sound blanket (top upper).

Remove the sound blanket (top lower).

Remove the sound blanket (back).

Remove the sound blanket (outer).

Remove the sound blanket (inner).

Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Fan Motor and Outdoor Fan Removal

Disconnect the connector [S70] for the fan motor.

Release the clamp from the partition plate.

Release the fan motor lead wire from the groove and the 2 hooks of the partition plate.

Remove the nut and remove the outdoor fan. Nut size: M6

Remove the 2 screws of the fan motor fixing frame.

Ensure all power supplies are turned off for at least 10 minutes before starting disassembly.

Disconnect connectors and pull out clamps

Unfasten the 4 hooks at the bottom

Unfasten the 2 hooks and remove the main PCB

Warning: Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the 4 screws from the top panel

Remove the 4 screws from the discharge grille

Slide the discharge grille upward and remove it

Check for hooks on the discharge grille

Take care not to cut your finger by the fins of the outdoor heat exchanger
