Daikin Outdoor Unit Ceiling Mounted Cassette Type Heat Pump RX09RMVJU

Daikin Outdoor Unit Ceiling Mounted Cassette Type Heat Pump RX09RMVJU

Create an account to install this asset package.

Maintenance Plans for Daikin Outdoor Unit Ceiling Mounted Cassette Type Heat Pump Model RX09RMVJU

Integrate maintenance plans directly into your work orders in MaintainX.

Outdoor Fan Motor Check

Check mark

Check No.16: Make sure that the voltage is within 320 VDC.

Check mark

Set operation off and power off. Disconnect the connector S70 or S71.

Check mark

Voltage between the pins 4 - 7

Check mark

Control voltage between the pins 4 - 3

Check mark

Rotation command voltage between the pins 4 - 2

Check mark

Keep operation off and power off. Connect the connector S70 or S71.

Check mark

4 rotation pulses (0 ~ 15 VDC) at the pins 4 - 1 when the fan motor is rotated 1 turn by hand.

Check mark

Fuse melted?

Check mark

If NG in step 2 -> Defective PCB -> Replace the outdoor unit PCB (main PCB).

Run this procedureArrow right

Indoor Fan Motor Connector Output Check

Check mark

Check the connection of connector

Check mark

Check motor power supply voltage output (pins 5 ~ 8)

Check mark

Check motor control voltage (pins 5 ~ 4)

Check mark

Check rotation command voltage output (pins 5 ~ 3)

Check mark

Check rotation pulse input (pins 5 - 2)

Check mark

Sign off on the Indoor Fan Motor Connector Output Check

Run this procedureArrow right

Main Circuit Short Check

Check mark

Check No.20: Check to make sure that the voltage between (+) and (–) of the diode bridge (DB1) is approximately 0 V before checking.

Check mark

Enter the voltage between (+) and (–) of the diode bridge (DB1)

Check mark

Measure the resistance between the pins of the DB1 referring to the table below.

Check mark

Enter the resistance between the pins of the DB1

Check mark

Is the resistance is  or less than 1 k?

Check mark

If the resistance is  or less than 1 k, short circuit occurs on the main circuit.

Check mark

Sign off on the main circuit short check

Run this procedureArrow right

Power Supply Waveforms Chec

Check mark

Warning: This check requires trained personnel with PPE!

Check mark

Upload a photo of the power supply waveform between No. 1 and No. 2 on the terminal block

Check mark

Is the power supply waveform a sine wave?

Check mark

Is there waveform disturbance near the zero-cross?

Check mark

Sign off on the power supply waveforms check

Run this procedureArrow right

Thermistor Resistance Check

Check mark

Warning: Disconnect the connectors of the thermistors from the PCB before proceeding

Check mark

Thermistors disconnected from the PCB

Check mark

Measure the resistance of each thermistor using a multimeter

Check mark

Note: The data is for reference purpose only

Check mark

Room temperature thermistor removed from the control PCB

Check mark

Measure the resistance of the room temperature thermistor

Check mark

Indoor heat exchanger thermistor removed

Check mark

Measure the resistance of the indoor heat exchanger thermistor

Check mark

Sign off on the thermistor resistance check

Run this procedureArrow right
