The Daikin Air Conditioner FTXP35M5V1B is a high-efficiency cooling solution designed for residential and commercial applications. Known for its reliability and advanced technology, this model ensures optimal comfort and energy savings, making it a preferred choice for climate control.

Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant

PDF MANUAL

Manual for Daikin Air Conditioner FTXP35M5V1B

MAINTENANCE RESOURCES

Complete asset maintenance, one click away

Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.

Documents & Manuals

Find all the essential guides in one place.

Tensioning Guide
Belt-diagram
C-120 pulleys
+ 13 more

Work Order Templates

Pre-built workflows to keep your asset running smoothly.

Daily Electrical System Inspection
Replace Roller and Pulley
Install Engine B-120
+ 29 more

Procedures

Integrate maintenance plans directly into your work orders.

Motion Industries
Applied Industrial Technologies
Electrical Brothers
+ 5 more

Parts

Access the parts list for your equipment in MaintainX.

Drive Motor
B2 Rollers
Tensioning System
+ 40 more

Daikin Air Conditioner FTXP35M5V1B

Create an account to install this asset package.

Maintenance Plans for Daikin Air Conditioner Model FTXP35M5V1B

Integrate maintenance plans directly into your work orders in MaintainX.

1 Yearly Battery Replacement

Remove the back cover

Insert both batteries at once

Put the cover back

Run this procedure

3 Yearly Titanium Apatite Deodorizing Filter and Silver Particle Filter Replacement

Warning: Handle the filters with care to avoid damage

Tabs on the filter frame removed

Old filter removed from the tabs

Upload a photo of the new filter ready for installation

New filter installed in the filter frame

Old filter disposed as non-flammable waste

Sign off on the filter replacement

Run this procedure

6 Monthly Titanium Apatite Deodorizing Filter and Silver Particle Filter Cleaning

Warning: Handle the filters with care to avoid damage.

Remove the titanium apatite deodorizing and silver particle filters from the tabs

Remove the dust from the filter with a vacuum cleaner

Soak the filter for 10 to 15 minutes in warm water

Do NOT remove the filter from the frame

After washing, shake off remaining water and dry the filter in the shade

Do NOT wring out the filter when removing water

Sign off on the filter cleaning

Run this procedure

Indoor Unit and User Interface Cleaning

NOTICE! Do NOT use gasoline, benzene, thinner polishing powder or liquid insecticide. Possible consequence: Discoloration and deformation

Do NOT use water or air of 40°C or higher. Possible consequence: Discoloration and deformation

Do NOT use polishing compounds

Do NOT use a scrubbing brush. Possible consequence: The surface finishing peels off

DANGER: RISK OF ELECTROCUTION. Before cleaning, be sure to stop the operation, turn the breaker off or pull out the supply cord. Otherwise, an electric shock and injury may result

Did you stop the operation and turn off the breaker or pull out the supply cord before cleaning?

Did you use a soft cloth for cleaning?

If stains were difficult to remove, did you use water or a neutral detergent?

Sign off on the cleaning procedure

Run this procedure

2 Weekly Air Filter Cleaning

Push the tab at the centre of each air filter, then pull it down

Pull out the air filters

Remove the titanium apatite deodorizing filter and silver particle filter from the tabs

Wash the air filters with water or clean them with a vacuum cleaner

Soak in lukewarm water for about 10 to 15 minutes

If the dust does NOT come off easily, wash the air filters with a neutral detergent diluted in lukewarm water. Dry the air filters in the shade
