Curtis-Toledo Oil-Injected Rotary Screw Compressor RSB 40

Create an account to install this asset package.

Maintenance Plans for Curtis-Toledo Oil-Injected Rotary Screw Compressor Model RSB 40

Integrate maintenance plans directly into your work orders in MaintainX.

1 Weekly Oil-Injectedrotary Screw Compressor Maintenance

Pressure relief valve operation check

Drain condensate from sump

Check load/unload cycle

Check all electrical connections

Inspect/clean finned surface of radiators

Inspect hoses for signs of wear

Sign off on the weekly maintenance

Run this procedure

Standard Air Filter Replacement

Clean the exterior surfaces of the filter canister

Loosen the wing nut and remove the air filter cover

Remove the element and clean the interior surfaces

Inspect and/or replace the element

Replace the cover and retighten the wing nut

Run this procedure

1 Daily Oil-Injectedrotary Screw Compressor Maintenance

Check sump oil level (fill if necessary)

Check oil scavenger line for oil flow

Check pressure operating point and controls

Drain condensate from air receiver

Run this procedure

2000 Hourly / 6 Monthly Oil Filter Replacement

WARNING: Before performing any maintenance function, switch main disconnect switch to "off" position to assure no power is entering unit. "Lock Out" or "Tag Out" all sources of power. Be sure all air pressure in unit is relieved. Failure to do this may result in injury or equipment damage.

Shut down the unit, disconnect the power, lockout and tag to prevent accidental restarting.

Wait one (1) minute after the compressor stops to allow for the pressure to be relieved.

Using a strap wrench remove the old filter from the filter head.

Clean the gasket contact surface on the inside of the filter head.

Apply a light film of the compressor oil to the gasket surface on the new element.

Hand tighten the new element until the gasket is seated in the gasket groove.

Continue tightening the element by hand an additional ½ to ¾ turn.

Restart the unit and check for leaks.

Run this procedure

Compressor Oil Level Check

DANGER: Hot oil under pressure can cause severe injury, death and/or property damage. Be sure the compressor is shutdown and the pressure is relieved before attempting to change or add lubricant.

Compressor is shut down

Wait one (1) minute after the compressor stops to allow the pressure to be relieved and the lubricant to settle.

Lubricant level is at the center of the sight glass

Power is disconnected, lockout and tag to prevent accidental restarting

Dirt is cleaned from around the fill cap

Cap is loosened and any additional pressure is relieved through the vent holes, then removed

Lubricant is added to the proper level

Cap is replaced and tightened securely

Run this procedure
