Caterpillar Compact Track Loader 257

Refer to the Service Manual for the complete adjustment procedure for the engine valve lash.

A qualified mechanic should adjust the engine valve lash and the fuel injector timing because special tools and training are required.

Bogie and Idler Oil Level - Check

Steps to check Bogie and Idler Oil Level

Steps to change Hydraulic System Oil

Steps to lubricate Sprocket Bearings

Sign off on the maintenance procedure

Engine Crankcase Breather - Clean

Note: This type of engine crankcase breather is used on naturally aspirated engines only.

Note: Ensure that the area around the vent hole on the breather cover is clean and that the vent hole is not restricted. Ensure that the breather hose is installed correctly, so that the hose does not contact other parts. Ensure that the components of the breather assembly are seated in the correct positions. Otherwise, engine damage could result.

1. Open the engine access door. Refer to Operation and Maintenance Manual, “Access Doors and Covers”.

2. Tilt the radiator upward. Refer to Operation and Maintenance Manual, “Radiator Tilting”.

3. Loosen the hose clamps (1) for the breather hose. Remove the breather hose.

4. Remove the screws (3). Remove the breather cover (4).

5. Remove the diaphragm assembly (5). The diaphragm assembly consists of the diaphragm and the locating ring. Remove the spring (6).

6. Clean the following items with a clean, nonflammable solvent:

Did you apply lubricant to the grease fittings for the rear axle bearings and the front axle bearings?

Did the backup alarm sound immediately when the speed/direction control lever was moved to the REVERSE position?

Bogie and Idler - Inspect/Replace

Did you clean the undercarriage before inspecting the bogies and the idlers?

Did you inspect the bogies and idlers for damage and wear?

Did you maintain the coolant to the top of the sight gauge with the radiator in the LOWERED position?

WARNING: Personal injury can result from contact with refrigerant. Contact with refrigerant can cause frost bite. Keep face and hands away to help prevent injury. Protective goggles must always be worn when refrigerant lines are opened, even if the gauges indicate the system is empty of refrigerant. Always use precaution when a fitting is removed. Slowly loosen the fitting. If the system is still under pressure, release it slowly in a well ventilated area.

Personal injury or death can result from inhaling refrigerant through a lit cigarette. Inhaling air conditioner refrigerant gas through a lit cigarette or other smoking method or inhaling fumes released from a flame contacting air conditioner refrigerant gas, can cause bodily harm or death. Do not smoke when servicing air conditioners or wherever refrigerant gas may be present.

Use a certified recovery and recycling cart to properly remove the refrigerant from the air conditioning system.

NOTICE: If the refrigerant system has been open to the outside air (without being plugged) for more than 30 minutes, the receiver-dryer must be replaced. Moisture will enter an open refrigerant system and cause corrosion which will lead to component failure.

Refer to Service Manual, SENR5664, “Air Conditioning and Heating R-134a For All Caterpillar Machines” for the proper procedure to change the receiver-dryer assembly and for the procedure to reclaim the refrigerant gas.

Note: The receiver-dryer must also be replaced when the air conditioning system is evacuated.
