Bobcat Loader T86

Engine Air Filter display check

Service needed for Engine Air Filter or Air System?

Check for leaks and damaged components

Sign off on the Filters Display Check

Replaced the hydraulic main and charge filters?

Replaced the Hydraulic fluid and Hydraulic reservoir vent filter?

Replaced the fluid of Final Drive Transmissions (Chaincases)?

Cleaned the heater coil and air conditioning evaporator? Cleaned the plenum drain?

Replaced fuel pre-filter element and fuel tank vent filter of Fuel System?

Replaced engine oil and filter element every 750 Hours or every 12 months?

Replaced the Coolant every 1500 Hours or every 24 months?

Sign off on the loader maintenance

NOTE: The following steps are done before starting the loader.

Check level of Engine Oil and add as needed

Check for loose connections and damaged components of Engine Air Intake Ducting

Clean Engine Cooling System. Clean debris from radiator cooling package, air conditioning condenser (if equipped), rear grilles, and engine compartment

Check coolant level COLD and add premixed coolant as needed

Sign off on the 10 Hours Engine Maintenance

Lubricate with multipurpose lithium based grease

Check the condition of seat belt

Clean or replace seat belt retractors as needed

Check the seat bar and control interlocks for correct operation

Clean dirt and debris from moving parts

Check for correct function of Bobcat Interlock Control System (BICS)

Lift and Tilt functions MUST NOT operate with seat bar raised

Check for damaged tires and correct air pressure. Inflate to MAXIMUM pressure shown on the sidewall of the tire

Check condition of Accessory Drive Belt (Alternator, air conditioning, water pump). Replace as needed

Check the function of the lift arm bypass control in Bobcat Interlock Control System (BICS)

Check cables of Battery and connections
