Atlas Copco Oil-Injected Screw Compressor GA15VSDS FF

Remove the air filter element and inspect

Replace damaged or heavily contaminated elements

Check the filter elements of the electric cabinet

Replace filter elements of the electric cabinet if necessary

Fans at the bottom of the NEOS Next heat sink disassembled

Dirt removed from the fans with a fiber brush

Is vacuuming or blowing through the heat sink required?

Dirt removed from the heat sink at the bottom with a fiber brush

WARNING! The operator must apply all relevant safety precautions

Always drain the compressor oil at all drain points

Used oil left in the compressor can contaminate the oil system and can shorten the lifetime of the new oil

Never mix lubricants of different brands or types as they may not be compatible and the oil mix will have inferior properties

A label, indicating the type of oil filled ex factory, is stuck on the air receiver/oil tank

WARNING! Only genuine Atlas Copco oils to be used

Run the compressor until warm and stop the compressor

Open the manual drain valve slowly

WARNING! Do not use water or solvents to clean the condenser

Stop the compressor, close the air outlet valve and switch off the voltage

Remove any dirt on the condenser inlet with a vacuum cleaner

Clean with an air jet in the reverse direction to normal flow

Keep the compressed air nozzle more than 30 cm away from the condenser to avoid damaging the of condenser fins

Remove dust from inside the dryer, e.g. with a vacuum cleaner

Sign off on the condenser cleaning

Replace Smart Temperature Control (STC) valve

NOTE! For compressor elements used on operating pressures below or equal to 10 bar (145 psi), the service can be postponed to 32000 running hours;
