Atlas Copco AC Compressor XAS 185 KD7

Release the snap clips (1) and remove the dust trap (2). Clean the trap.

Remove the element (3) from the housing (5). If the element is to be serviced for immediate re-use, reinstall the dust trap to protect the air intake system while cleaning the element.

Reassemble in reverse order of dismantling.

Inspect and tighten all air intake connections.

Reset the vacuum indicator by pushing the reset button.

Replacement of fuel filter cartridge

Check & clean of water separator

Check & clean of fuel tank interior

Check & clean of water jacket and radiator interior

Keep the coolers clean to maintain the cooling efficiency.

Front cooler baffle is removable for access by unscrewing 4 bolts.

NOTE: Remove any dirt from the coolers with a fiber brush. Never use a wire brush or metal objects.

When cleaning by air jet, blow air through the cooler in reverse direction of normal flow.

If the dirt is oily, wash the coolers with degreaser or a cleansing agent.

NOTE: Protect the electrical and controlling equipment, air filters etc. against penetration of moisture.

A spray gun should preferably be used to apply the solvent to the fins.

Rinse the blocks by means of a water jet max. 100 psi at 2 inch distance after a soaking-in period.

NOTE: To avoid damaging the coolers, angle between waterjet and coolers should be approx. 90º.
