ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0820A-5
Create an account to install this asset package.
Maintenance Plans for ABB Enclosed Variable Speed/Frequency Drive Model ACS880-07-0820A-5
Integrate maintenance plans directly into your work orders in MaintainX.
6 Yearly ZCU-14 Control Unit Battery Replacement
Warning: For trained personnel only. Follow safety instructions of the drive.
Drive stopped and electrical safety precautions followed
M4×8 (T20) screws at the ends of the control unit removed
XD2D terminal block removed to see the battery
Edge of the control unit cover on the side with the I/O terminal blocks carefully lifted
Battery pulled out of the battery holder
New CR2032 battery inserted into the battery holder
Control unit cover closed
M4×8 (T20) screws tightened
ZCU-14 Memory Unit Replacement
WARNING! Do not remove or insert the memory unit when the control unit is powered.
WARNING! Obey the safety instructions of the drive. If you ignore them, injury or death, or damage to the equipment can occur. If you are not a qualified electrical professional, do not do installation, commissioning or maintenance work.
Drive stopped and electrical safety precautions followed?
Clip of the memory unit pulled forward?
Memory unit taken off?
Memory unit replaced in reverse order?
Sign off on the memory unit replacement
6 Yearly ZCU-12 Control Unit Battery Replacement
Warning: For trained personnel only
Drive stopped and electrical safety precautions followed
Upload a photo of the battery ejector in the battery slot
Battery carefully pulled out of the battery holder
Upload a photo of the new CR2032 battery
New CR2032 battery carefully put into the battery holder
Sign off on the battery replacement
9 Yearly Circuit Board Compartment Cooling Fan Replacement
WARNING! Obey the safety instructions of the drive. If you ignore them, injury or death, or damage to the equipment can occur. If you are not a qualified electrical professional, do not do installation, commissioning or maintenance work.
Drive stopped and electrical safety precautions followed
Drive module removed from the cabinet
Fastening screw of the fan enclosure undone
Power supply cable of the fan unplugged
New fan installed in reverse order
Counter reset in group 5 in the primary control program
Sign off on the fan replacement
ZCU-12 Memory Unit Replacement
Warning: Do not remove or insert the memory unit when the control unit is powered.
Drive stopped and electrical safety precautions followed
Upload a photo of the memory unit before removal
Clip at the side of the memory pulled up
Memory unit removed
Upload a photo of the memory unit after removal
Memory unit installed in reverse order
Upload a photo of the memory unit after installation
Sign off on the memory unit replacement
Parts for ABB Enclosed Variable Speed/Frequency Drive ACS880-07-0820A-5
Access the parts list for your equipment in MaintainX.
Sine Filter
NSIN0900-6
Fuse IEC
170M6416
Fuse UL
170M6416
Fuse IEC
SC33AR69V13CTF
Sine Filter
NSIN0900-6
Fuse IEC
170M6416
Fuse UL
170M6416
Fuse IEC
SC33AR69V13CTF
Sine Filter
