Stelrad Group Boiler CX.205

Stelrad Group Boiler CX.205

Create an account to install this asset package.

Maintenance Plans for Stelrad Group Boiler Model CX.205

Integrate maintenance plans directly into your work orders in MaintainX.

1 Yearly Overheat Thermostat Replacement

Check mark

WARNING: Safety Precautions

Check mark

Removal of Old Thermostat

Check mark

Turn off the gas supply at the inlet gas cock.

Check mark

Switch off and disconnect the electricity supply.

Check mark

Remove the push-on tags and earth connection on the overheat thermostat body, noting their position.

Check mark

Undo the two screws retaining the thermostat/piezo igniter bracket to the gas valve.

Check mark

Undo the two screws retaining the thermostat.

Check mark

Remove the retaining clip from the thermostat pocket and remove the overheat thermostat phial.

Check mark

Installation of New Thermostat

Run this procedureArrow right

1 Yearly L.E.D. Lights Assembly Option C Replacement

Check mark

Safety Precautions

Check mark

Turn OFF the gas supply at the inlet gas cock

Check mark

Switch OFF and DISCONNECT the electricity supply

Check mark

Remove Controls Box Front Panel

Check mark

Undo the two screws securing the controls box front panel

Check mark

Lower the front panel to clear the location pegs

Check mark

Pull the front panel away from the controls box

Check mark

Unplug the potentiometer lead a-pin socket and the two leads from printed circuit board No. 5 off circuit board No. 1 and the L.E.D lights plug off board No. 3

Check mark

Place the front panel on a suitable work surface

Run this procedureArrow right

1 Yearly Electronic Boiler Thermostat Potentiometer and Sensor Replacement

Check mark

Safety Precautions

Check mark

Turn off the gas supply at the inlet gas cock

Check mark

Switch off and disconnect the electricity supply

Check mark

Remove Main Boiler Thermostat Sensor

Check mark

Remove the retaining clip from the thermostat pocket

Check mark

Remove the earth connection

Check mark

Disconnect the two push-on leads connecting the controls box to the overheat thermostat

Check mark

Detach Controls Box

Check mark

Remove the two screws securing the controls box to the side panels

Run this procedureArrow right

System Testing

Check mark

General

Check mark

Check that the system has been filled and properly vented

Check mark

Ensure all drain cocks are closed and stop valves are open

Check mark

Purging

Check mark

Is the electricity supply switched OFF?

Check mark

Remove the jacket lower front panel

Check mark

Safety precautions

Check mark

Is the gas supply turned ON at the meter?

Check mark

Open the gas supply cock

Run this procedureArrow right

Manifold Gas Pressure Check

Check mark

Preparation

Check mark

Ensure the system is cold and on full load with all temperature controls set at maximum.

Check mark

Remove the screw in the manifold setting pressure test nipple and connect a suitable gas pressure gauge.

Check mark

Pressure Adjustment

Check mark

Light the boiler and allow it to operate for about fifteen minutes to stabilize the burners.

Check mark

Check the manifold gas pressure.

Check mark

Adjust the pressure to the figure shown in Table 1 for the appropriate boiler size.

Check mark

Remove the dust cover over the adjuster.

Check mark

Using a small screwdriver, turn the screw beneath clockwise to increase or anti-clockwise to decrease pressure.

Run this procedureArrow right
